Hioki 3554-51 Battery Tester

The Hioki 3554-51 Battery Tester is a handheld device that is designed to help you quickly and accurately test the health of your batteries. It is a highly reliable and efficient device that is ideal for ensuring that your batteries are operating at their maximum potential.

SKU: 69332

MME Shopping Event

Hurry and get discounts on Most of MME Products up to 20%

Original price was: AED 6,500.Current price is: AED 6,194. (excl.VAT)

11 People watching this product now!

Hioki 3554-51 Battery Tester

The Hioki 3554-51 Battery Tester is a portable battery tester that measures AC resistance. It is designed to help businesses maintain their UPSs and storage batteries. The BT3554 battery internal resistance tester establishes a standard for determining battery life and deterioration by giving a complete diagnosis via the battery resistance tests.

Features

The Hioki 3554-51 Battery Tester has several features that make it an ideal tool for battery testing. These include:

  • Battery measurement can be performed while the battery is connected to its host device, without taking it offline.
  • Measure and save data in as fast as 2 seconds, a 60% improvement from the legacy 3554.
  • Instantaneously diagnose battery degradation (PASS, WARNING, FAIL) by measuring internal resistance and voltage.
  • Measurement circuit that’s more resistant to noise than previous models.
  • Increased measurement efficiency thanks to new compact, lightweight probes.
  • Store up to 4,800 data points in built-in memory and transfer to PC via USB.

Applications

The Hioki 3554-51 is a versatile tool that can be used in various industries for measuring the resistance of batteries. In Quality Control, it can be employed to ensure that lead-acid batteries meet the required specifications. In Electrical Engineering, it can assist in designing and testing battery systems. In Manufacturing, it can help to ensure that batteries meet the required resistance specifications. In Research and Development, it can be used to measure the resistance of new battery materials and components.

Hioki 3554-51 Battery Tester Specifications:

  • Measurement parameters:
    • Battery internal resistance measurement
    • Battery terminal voltage measurement (DC voltage only)
    • Temperature measurement (when using 9460, 9451, or 9451S)
  • Measurement time: 100 ms
  • Response time: Approx. 1.6 sec.
  • Location of use: Indoors, Level 2 pollution, maximum elevation of 2000 m (6562 ft.)
  • Operating temperature and humidity range:
    • Temperature: 0°C to 40°C (32°F to 104°F)
    • Humidity: 80% RH or less (non-condensing)
  • Storage temperature and humidity range:
    • Temperature: -10°C to 50°C (14°F to 122°F)
    • Humidity: 80% RH or less (non-condensing)
  • Power supply:
    • Size AA alkaline battery (LR6) × 8
    • Rated supply voltage: 1.5 V DC × 8 (Nickel metal hydride batteries may be used. However, the battery life display is not supported in this configuration.)
  • Continuous operating time:
    • About 8.3 hr. (without Z3210 installed)
    • About 8.2 hr. (with Z3210 installed and wireless communications active)
  • Standard compliance:
    • Safety: EN 61010-2-030
    • EMC: EN 61326-1
  • Dimensions: 199W × 132H × 60.6D mm (7.83″W × 5.20″H × 2.39″D) (with Protector Z5041 installed)
  • Mass: 960 g (33.9 oz.) (including batteries and Protector Z5041)
  • Communications interface: USB Wireless communications (when Z3210 installed)
  • Product warranty 3 years
  • Fuse 250 V, F 630 mAH (Littelfuse model 216.630)

Battery Testing/Battery Capacity Tester Template

  • Min Voltage: 6 V
  • Max Voltage: 60 V
  • Min Resistance: 3 m Ohms
  • Max Resistance (ohm): 3 Ohms
  • Accuracy: ±0.8 % rdg ±6 dgt (3 mΩ range: ±1.0 % rdg ±8 dgt)
0 reviews
0
0
0
0
0

There are no reviews yet.

Be the first to review “Hioki 3554-51 Battery Tester”

Brand

Hioki

Hioki is a renowned Japanese brand known for its expertise in developing and manufacturing electrical measuring instruments. The company, Hioki E.E. Corporation, was established in 1935, and since then, it has committed itself to providing innovative solutions in the field of electrical measurement.

Hioki's product range is extensive, including devices such as digital multimeters, clamp meters, power meters, and oscilloscopes. These instruments are vital for various applications in research and development, maintenance, and production testing across industries like electronics, energy, and automotive. One of the key strengths of Hioki is its focus on precision and reliability, traits that are crucial in measurement instruments. Hioki’s products are designed to offer accuracy and durability, which make them preferred choices among professionals worldwide.

Moreover, Hioki emphasizes technological innovation and quality. The company invests significantly in research and development to keep up with evolving technological trends and to ensure their products meet the highest standards. This commitment to quality is reflected in their adherence to international certifications and standards. Hioki also values environmental sustainability, integrating eco-friendly practices in their operations and product designs. This includes efforts to reduce the environmental impact of their manufacturing processes and to design products that are energy efficient.

Hioki logo brand

Datasheet

Datasheet

Datasheet

Specifications

Technical Specifications

Specification Details
Measurement Parameters Battery internal resistance, battery terminal voltage (DC only), temperature (with sensors 9460, 9451, 9451S)
Measurement and Response Time Measurement time: 100 ms, Response time: Approx. 1.6 sec.
Location of Use Indoors, Level 2 pollution, up to 2000 m elevation
Operating Conditions Temperature: 0°C to 40°C (32°F to 104°F), Humidity: 80% RH or less (non-condensing)
Storage Conditions Temperature: -10°C to 50°C (14°F to 122°F), Humidity: 80% RH or less (non-condensing)
Power Supply Size AA alkaline batteries (LR6) × 8, 1.5 V DC × 8; Nickel metal hydride batteries possible (battery life display not supported)
Continuous Operating Time About 8.3 hr. (without Z3210); 8.2 hr. (with Z3210 and wireless active)
Standard Compliance Safety: EN 61010-2-030, EMC: EN 61326-1
Dimensions and Mass 199W × 132H × 60.6D mm (7.83″W × 5.20″H × 2.39″D), 960 g (33.9 oz.) including batteries and Protector Z5041
Communications Interface USB, Wireless communications (when Z3210 installed)
Product Warranty 3 years
Fuse 250 V, F 630 mAH (Littelfuse model 216.630)
Battery Testing Range Min Voltage: 6 V, Max Voltage: 60 V, Min Resistance: 3 mΩ, Max Resistance: 3 Ω, Accuracy: ±0.8% rdg ±6 dgt (3 mΩ range: ±1.0% rdg ±8 dgt)
