Name: Buy MARMONIX MFU-6100 Ultrasonic Flow meter | mme-ae
Brand: Marmonix
SKU: 98923
Price: 1200 AED
Availability: InStock

Buy MARMONIX MFU-6100

The MARMONIX MFU-6100 Ultrasonic Flow Meter is a cutting-edge instrument for precise liquid flow measurement. This meter provides reliable and accurate readings using advanced ultrasonic transit-time technology, making it ideal for various industrial applications. Its modular design allows easy integration into existing systems, enhancing versatility and functionality.

Key Features

The MFU-6100 offers several key features that set it apart from traditional flow measurement devices:

High Accuracy: The ultrasonic technology ensures minimal measurement errors, providing confidence in data reliability.
Versatile Applications: Suitable for a wide range of liquids, including water, oils, and chemicals, the MFU-6100 can be used in various industries such as water treatment, food processing, and petrochemicals.
User-Friendly Interface: Equipped with an intuitive display and straightforward controls, the device allows for easy operation and monitoring.
Modular Design: Modular construction enables customization based on specific requirements, facilitating upgrades and maintenance.
Robust Construction: Designed to withstand harsh environments, the MFU-6100 is built with durable materials that ensure longevity and reliability.

Applications

The MARMONIX MFU-6100 Ultrasonic Flow Meter suits numerous applications across different sectors. Its ability to measure flow accurately makes it valuable in:

Water Supply Management: Monitoring water flow in municipal systems helps manage efficient resources.
Chemical Processing: Ensuring precise flow measurement in chemical plants aids in maintaining product quality and safety.
Food and Beverage Industry: Accurate flow measurement is crucial for compliance with health regulations and maintaining product consistency.
HVAC Systems: The MFU-6100 can effectively monitor chilled water or hot water flows in heating and cooling systems.

MARMONIX MFU-6100 Specifications

The MARMONIX MFU-6100 has an accuracy of ±1 reading at rates greater than 0.2 mps and is suitable for pipes ranging from DN 15mm to DN 6000mm

Accuracy:	±1 of reading at rates >0.2 mps
Repeatability:	0.20%
Velocity:	transmit time
Pipe size:	DN 15mm-DN 6000mm
Display:	LCD with backlight displays accumulated flow/heat, instantaneous flow/heat, velocity, time, etc.
Signal output:	1 way 4-20mA output, 1 way OCT pulse output, 1 way relay output
Signal input:	3-way 4-20mA input achieved to heat measurement by connecting PT100 platinum resistor
Pipe material:	Carbon steel, stainless steel, cast iron, cement pipe, copper, PVC, Aluminum, FRP etc.
Liquid types:	All kinds of clean and pure liquids.
Power supply:	DC24V
Power consumption:	less than 1.5W

Buy the MARMONIX MFU-6100 Ultrasonic Flow Meter for accurate liquid flow measurement. Its advanced technology and robust design make it ideal for various industries. Its modular capabilities deliver immediate benefits and future scalability.

Accuracy	±1 of reading at rates >0.2 mps
Repeatability	0.2%
Velocity	transmit time
Pipe size	DN 15mm-DN 6000mm
Display	LCD with backlight, display accumulated flow/heat, instantaneous flow/heat, velocity, time etc.
Signal output	1 way 4-20mA output, 1 way OCT pulse output, 1 way relay output
Signal input	3 way 4-20mA input achieve to heat measurement by connecting PT100 platinum resistor
Pipe material	carbon steel, stainless steel,cast iron, cement pipe, copper, PVC, Aluminum, FRP etc.
Liquid types	all kinds of clean and pure liquids.
Power Supply	dc24v less than 1.5w power consumption

Specifications

Accuracy:	±1 of reading at rates >0.2 mps
Repeatability:	0.20%
Velocity:	transmit time
Pipe size:	DN 15mm-DN 6000mm
Display:	LCD with backlight, display accumulated flow/heat, instantaneous flow/heat, velocity, time etc.
Signal output:	1 way 4-20mA output, 1 way OCT pulse output, 1 way relay output
Signal input:	3 way 4-20mA input achieve to heat measurement by connecting PT100 platinum resistor
Pipe material:	carbon steel, stainless steel,cast iron, cement pipe, copper, PVC, Aluminum, FRP etc.
Liquid types:	all kinds of clean and pure liquids.
Power supply:	DC24V
Power consumption:	less than 1.5W

Datasheet
