Testo 890 Thermal Imager X1
2 Comments
Experience precise thermal imaging with Testo 890 X1, ideal for in-depth inspections and diagnostics. Enhance your work’s accuracy today.
Terms of sending goods ›
AED 46,279 (excl.VAT)
Order Via phone number
Order Via Online Form
In Stock
Description
Testo 890 Thermal Imager X1
The Testo 890 Thermal Imager X1 utilizes infrared technology to detect and visualize thermal patterns and temperature differences. It has a high-resolution detector that captures detailed thermal images, allowing users to identify and analyze thermal anomalies effectively.
To buy testo 890 be in touch with our experts. As a well-known distributor, MMElectronic is pleased to meet all of your requirements for thermal cameras by providing the greatest international brands at cost-effective pricing.
The Testo 890 professional thermal imager means you are ideally equipped for the following applications:
- Safe high-temperature measurement
- Analysis of building shells at a Glance
- Regular checks in electrical maintenance
- Precise visualization of critical temperatures on circuit boards
- Carrying out detailed energy consultancy
- Analysis of energy distribution systems
Testo 890 Thermal Imager X1 Specifications:
- EU-/EG-guidelines: 2004/108/EG
- Infrared resolution : 640 x 480 pixels
- Thermal sensitivity : ˂ 40 mK at +30 °C
- Field of view : 42° x 32° (Standard lens), 25° x 19° (25° lens), 15° x 11° (Telephoto lens), 6.6° x 5° (Supertele)
- Minimum focus distance: 0.1 m (Standard lens), 0.2 m (25° lens), 0.5 m (Telephoto lens), 2 m (Supertele)
- Geometric resolution (IFOV): 1.13 mrad (Standard lens), 0.68 mrad (25° lens), 0.42 (Telephoto lens), 0.18 (Supertele)
- SuperResolution (Pixel) : 1280 x 960 pixels
- SuperResolution (IFOV) : 0.71 mrad (Standard lens), 0.43 mrad (25° lens), 0.26 mrad (Telephoto lens), 0.11 mrad (Supertele)
- Image refresh rate: 33 Hz
- Focus: auto/manual
- Spectral range: 7.5 to 14 µm
- size: 3.1 MP
- Minimum focus distance: 0.5 m
- Tripod mounting : 1/4″ – 20UNC
- Product-/housing material: ABS
- weight (without package): 1,630 g
- Weight: 1630 g
- Dimensions : 253 x 132 x 111 mm
Additional information
| max___temperature___cat (thermal camera) |
Above 1000°C |
|---|---|
| infrared___resolution___cat (thermal camera) |
High (above 320 x 240) |
Datasheet
Datasheet
Technical data
Technical data
| Feature | Specification |
|---|---|
| EU-/EG Guidelines | 2004/108/EG |
| Infrared Resolution | 640 × 480 pixels |
| Thermal Sensitivity | < 40 mK at +30 °C |
| Field of View | 42° × 32° (Standard lens), 25° × 19° (25° lens), 15° × 11° (Telephoto lens), 6.6° × 5° (Supertele) |
| Minimum Focus Distance | 0.1 m (Standard lens), 0.2 m (25° lens), 0.5 m (Telephoto lens), 2 m (Supertele) |
| Geometric Resolution (IFOV) | 1.13 mrad (Standard lens), 0.68 mrad (25° lens), 0.42 mrad (Telephoto lens), 0.18 mrad (Supertele) |
| SuperResolution (Pixel) | 1280 × 960 pixels |
| SuperResolution (IFOV) | 0.71 mrad (Standard lens), 0.43 mrad (25° lens), 0.26 mrad (Telephoto lens), 0.11 mrad (Supertele) |
| Image Refresh Rate | 33 Hz |
| Focus | Auto / Manual |
| Spectral Range | 7.5 – 14 µm |
| Image Size | 3.1 MP |
| Minimum Focus Distance (Additional) | 0.5 m |
| Tripod Mounting | 1/4″ – 20UNC |
| Product / Housing Material | ABS |
| Weight (without package) | 1,630 g |
| Weight | 1,630 g |
| Dimensions | 253 × 132 × 111 mm |
