Description

The Fluke 283 FC is a high-performance digital multimeter designed for electrical and electronics applications. With its CAT III 1500V safety rating, it provides accurate measurements in a wide range of environments.

Whether you’re working on industrial equipment, electrical panels, or electronic circuits, the Fluke 283 FC delivers reliable results with its high-resolution display and compact, ergonomic design.

Fluke 283 Key Features

The Fluke 283 FC offers a range of measurement functions, including AC and DC volts, continuity, resistance, capacitance, and frequency. Its high accuracy and resolution make it ideal for applications where precise measurements are critical.

Range AC volts: 6.000 V, 60.00 V, 600.0 V, 1000 V
Range DC volts: 6.000 V, 60.00 V, 600.0 V, 1500 V
AC mV: 600.0 mV
DC mV: 600.0 mV
Continuity: 600 Ω
Resistance: 600.0 Ω, 6.000 kΩ, 60.00 kΩ, 600.0 kΩ, 6.000 MΩ, 50.00 MΩ
Capacitance: 1000 nF, 10.00 μF, 100.0 μF, 9999 μF
Frequency: 99.99 Hz, 999.9 Hz, 9.999 kHz, 99.99 kHz
AC VA (45 Hz ~ 500 Hz): 360.0 VA, 3.600 kVA, 36.00 kVA, 60.00 kVA
DC VA: 360.0 VA, 3.600 kVA, 36.00 kVA, 90.00 kVA

Who Needs the Fluke 283?

The Fluke 283 FC is designed for technicians, engineers, and buyers who require accurate and reliable measurements in electrical and electronics applications. Its CAT III 1500V safety rating and wide range of measurement functions make it an ideal choice for industrial, commercial, and residential settings.

Fluke 283 Applications

Use for electrical panel testing and troubleshooting
Measure voltage and current in industrial equipment
Test continuity and resistance in electronic circuits
Measure capacitance and frequency in power supplies
Use for electrical safety testing and certification
Measure voltage and current in residential and commercial electrical systems
Test and troubleshoot electrical panels and equipment

Why Buy Fluke 283 from MME?

At MME, we offer the Fluke 283 FC at competitive prices, along with expert advice and support. Our team of technicians and engineers can help you choose the right multimeter for your needs and provide training and certification programs to ensure you get the most out of your investment.

Fluke 283 Specifications

Function	Range	Resolution	Accuracy
AC volts^[1]	6.000 V	0.001 V	1.0 % + 3 (45 Hz to 500 Hz)
	60.00 V	0.01 V	1.0 % + 3 (45 Hz to 500 Hz)
	600.0 V	0.1 V	2.0 % + 3 (500 Hz to 1 kHz)
	1000 V	1 V	2.0 % + 3 (500 Hz to 1 kHz)
DC volts	6.000 V	0.001 V	0.09 % + 3
	60.00 V	0.01 V
	600.0 V	0.1 V
	1500 V	1 V	0.15 % + 2
AC mV^[1]	600.0 mV	0.1 mV	1.0% + 3 (45 Hz ~ 500 Hz) 2.0% + 3 (500 Hz ~ 1000 Hz)
DC mV	600.0 mV	0.1 mV	0.09 % + 2
Continuity	600 Ω	1 Ω
Resistance	600.0 Ω	0.1 Ω	0.5 % + 4
	6.000 kΩ	0.001 kΩ
	60.00 kΩ	0.01 kΩ
	600.0 kΩ	0.1 kΩ
	6.000 MΩ	0.001 MΩ
	50.00 MΩ	0.01 MΩ	1.5 % + 4
Capacitance	1000 nF	1 nF	1.2 % + 2
	10.00 μF	0.01 μF
	100.0 μF	0.1 μF
	9999 μF	1 μF	10 % typical
Frequency	99.99 Hz	0.01 Hz	0.1 % + 2
	999.9 Hz	0.1 Hz
	9.999 kHz	0.001 kHz
	99.99 kHz	0.01 kHz
AC VA (45 Hz ~ 500 Hz)^[1]	360.0 VA	0.1 VA	2 % + 1.0 VA
	3.600 kVA	0.001 kVA	2 % + 0.01 kVA
	36.00 kVA	0.01 kVA	2 % + 0.1 kVA
	60.00 kVA	0.01 kVA	2 % + 0.15 kVA
DC VA^[1]	360.0 VA	0.1 VA	2 % + 1.0 VA
	3.600 kVA	0.001 kVA	2 % + 0.01 kVA
	36.00 kVA	0.01 kVA	2 % + 0.1 kVA
	90.00 kVA	0.01 kVA	2 % + 0.25 kVA
Min-max avg	For DC functions, accuracy is the specified accuracy of the measurement function ± 12 counts for changes longer than 350 ms in duration.
Min-max avg	For AC functions, accuracy is the specified accuracy of the measurement function ± 40 counts for changes longer than 900 ms in duration.
