Fluke 5430 Standard AC/DC Resistors

The Fluke 5430 Standard AC/DC Resistors are designed to provide accurate and reliable measurements in a variety of applications. With a low tolerance of 10 ppm and high stability, these resistors are ideal for use in precision measurement systems.

Available from MME, these resistors offer a wide range of resistance values, making them suitable for use in a variety of industries, including electronics, automotive, and aerospace.

Fluke 5430 Key Features

The Fluke 5430 Standard AC/DC Resistors feature a number of key specifications, including:

• Tolerance: 10 ppm
• Calibration Uncertainty: AC: 3 ppm (10 kΩ: 4 ppm), DC: 1 ppm (optional)
• Long-Term Stability: 2 ppm per year
• Temperature Coefficient: 2 ppm per °C
• Recommended Current: 1Ω: 100 mA, 10Ω: 32 mA, 25Ω: 20 mA, 100Ω: 10 mA, 1 kΩ: 3 mA, 10 kΩ: 1 mA
• Maximum Current: 1Ω: 1 A, 10Ω: 320 mA, 25Ω: 200 mA, 100Ω: 100 mA, 1 kΩ: 32 mA, 10 kΩ: 10 ma
• AC/DC Transfer Error: 0.1 ppm, typical

Who Needs the Fluke 5430?

The Fluke 5430 Standard AC/DC Resistors are designed for use in a variety of applications, including precision measurement systems, calibration equipment, and test and measurement instruments. They are ideal for technicians and engineers who require accurate and reliable measurements.

Fluke 5430 Applications

• Use in precision measurement systems for accurate and reliable measurements
• Calibration of measurement instruments for high accuracy and reliability
• Use in test and measurement equipment for precise and reliable measurements
• Design and development of measurement systems for high accuracy and reliability
• Research and development of new measurement technologies for high accuracy and reliability
• Use in industrial automation and control systems for precise and reliable measurements
• Use in medical and healthcare applications for high accuracy and reliability

Why Buy Fluke 5430 from Mohammad Mahdi Electronics?

At Mohammad Mahdi Electronics, we offer the Fluke 5430 Standard AC/DC Resistors as part of our commitment to providing high-quality measurement solutions. With our expertise and knowledge, we can help you find the right product for your needs and provide you with the support and service you require.

Fluke 5430 Specifications
