Description

The Fluke Calibration 9143 Field Metrology Well is a cutting-edge solution for precise temperature measurement in demanding environments. With a temperature range of 33°C to 350°C, this instrument is designed to withstand the toughest conditions.

Featuring a high-precision display with an accuracy of ±0.2°C, the Fluke Calibration 9143 Field Metrology Well ensures reliable results every time. Its RS-232 interface enables seamless data transfer, making it easy to integrate into your existing workflow.

Fluke Calibration 9143 Field Metrology Well Key Features

This advanced instrument boasts a range of impressive specifications, including:

Temperature range: 33°C to 350°C
Display accuracy: ±0.2°C
Full Range Stability: ±0.02°C at 33°C, ±0.02°C at 200°C, ±0.03°C at 350°C
Axial uniformity: ±0.04°C at 33°C, ±0.1°C at 200°C, ±0.2°C at 350°C
Radial uniformity: ±0.01°C at 33°C, ±0.015°C at 200°C, ±0.02°C at 350°C
Loading effect: ±0.015°C
Full Range Hysteresis: 0.03

Who Needs the Fluke Calibration 9143 Field Metrology Well?

This instrument is designed for professionals who require precise temperature measurement in extreme environments. Whether you’re working in industrial, scientific, or research applications, the Fluke Calibration 9143 Field Metrology Well is the perfect solution.

From calibration and testing to quality control and research, this instrument is designed to meet the demands of your industry.

Fluke Calibration 9143 Field Metrology Well Applications

Temperature measurement in extreme environments
Calibration and testing of temperature sensors
Quality control and assurance
Research and development
Industrial process control
Scientific research

Why Buy Fluke Calibration 9143 Field Metrology Well from MME?

At MME, we’re committed to providing our customers with the highest-quality instruments and exceptional service. The Fluke Calibration 9143 Field Metrology Well is a testament to our dedication to precision and accuracy.

With accredited calibration included and automation capabilities, this instrument is designed to enhance your workflow and improve your results.

Fluke Calibration 9143 Field Metrology Well Specifications

Base Unit Specifications
Temperature range at 23°C	33°C to 350°C (91°F to 662°F)
Display accuracy	±0.2°C Full Range
Stability	±0.02°C at 33°C ±0.02°C at 200°C ±0.03°C at 350°C
Axial uniformity at 40 mm (1.6 in)	±0.04°C at 33°C ±0.1°C at 200°C ±0.2°C at 350°C
Radial uniformity	±0.01°C at 33°C ±0.015°C at 200°C ±0.02°C at 350°C
Loading effect (with a 6.35 mm reference probe and three 6.35 mm probes)	±0.015°C Full Range
Hysteresis	0.03
Operating conditions	0°C to 50°C, 0% to 90% RH (non-condensing)
Environmental conditions (for all specifications except temperature range)	13°C to 33°C
Immersion (well) depth	150 mm (5.9 in)
Insert OD	25.3 mm (1.00 in)
Heating time	5 min: 33°C to 350°C
Cooling time	32 min: 350°C to 33°C 14 min: 350°C to 100°C
Resolution	0.01°
Display	LCD, °C or °F user-selectable
Size (H x W x D)	290 x 185 x 295 mm (11.4 x 7.3 x 11.6 in)
Weight	7.3 kg (16 lb)
Power requirements	100 V to 115 V (±10%), 50/60 Hz, 1400 W 230 V (±10%), 50/60 Hz, 1800 W
Computer interface	RS-232 interface
Calibration	Accredited calibration included
Automation	Use the 1586A Super-DAQ to automate temperature sensor calibration
-P specifications
Built-in reference thermometer readout accuracy (4-Wire reference probe)¹	±0.010°C at -25°C ±0.015°C at 0°C ±0.020°C at 50°C ±0.025°C at 150°C ±0.030°C at 200°C ±0.040°C at 350°C ±0.050°C at 420°C ±0.070°C at 660°C
Reference resistance range	0 ohms to 400 ohms
Reference resistance accuracy²	0 ohms to 42 ohms: ±0.0025 ohms 42 ohms to 400 ohms: ±60 ppm of reading
Reference characterizations	ITS-90, CVD, IEC-751, Resistance
Reference measurement capability	4-wire
Reference probe connection	6-pin Din with Infocon Technology
Built-in RTD thermometer readout accuracy	NI-120: ±0.015°C at 0°C PT-100 (385): ±0.02°C at 0°C PT-100 (3926): ±0.02°C at 0°C PT-100 (JIS): ±0.02°C at 0°C
RTD resistance range	0 ohms to 400 ohms
RTD resistance accuracy‡	0 ohms to 25 ohms: ±0.002 ohms 25 ohms to 400 ohms: ±80 ppm of reading
RTD characterizations	PT-100 (385),(JIS),(3926), NI-120, Resistance
RTD measurement capability	4-wire RTD (2-,3-wire RTD w Jumpers only)
RTD connection	4 terminal input
Built-in TC thermometer readout accuracy	Type J: ±0.7°C at 660°C Type K: ±0.8°C at 660°C Type T: ±0.8°C at 400°C Type E: ±0.7°C at 660°C Type R: ±1.4°C at 660°C Type S: ±1.5°C at 660°C Type M: ±1.4°C at 660°C Type L: ±0.7°C at 660°C Type U: ±0.75°C at 600°C Type N: ±0.9°C at 660°C Type C: ±1.1°C at 660°C
TC millivolt range	–10 mV to 75 mV
Voltage accuracy	0.025% of reading + 0.01 mV
Internal cold junction compensation accuracy	±0.35°C (ambient of 13°C to 33°C)
TC connection	Small connectors
Built-in mA readout accuracy	0.02% of reading + 2 mV
mA range	Cal 4-22 mA, Spec 4-24 mA
mA connection	2 terminal input
Loop power function	24 V DC loop power
Built-in electronics temperature coefficient (0°C to 13°C, 33°C to 50°C)	±0.005% of range per °C
1. The temperature range may be limited by the reference probe connected to the readout. The Built-In Reference Thermometer Readout Accuracy does not include the sensor probe accuracy. It does not include the probe uncertainty or probe characterization errors. 2. Measurement accuracy specifications apply within the operating range and assume 4-wires for PRTs. With 3-wire RTDs add 0.05 ohms to the measurement accuracy plus the maximum possible difference between the resistances of the lead wires.
