Description

Accurate temperature reference is crucial for precise measurements in various industries. Fluke Mini Fixed-Point Cells provide a reliable solution for laboratory and industrial applications. With a wide range of fixed-point cells available, you can choose the one that suits your specific needs.

Fluke Mini Fixed-Point Cells Key Features

The Fluke Mini Fixed-Point Cells are designed to provide accurate temperature reference for precise measurements. They are easy to use and maintain, making them perfect for laboratory and industrial applications.

Model 5901B-G: Water T.P.
Model 5914A: Indium F.P.
Model 5915A: Tin F.P.
Model 5916A: Zinc F.P.
Model 5917A: Aluminum F.P.
Model 5918A: Silver F.P.
Model 5919A: Copper F.P.
Model 5944: Indium F.P.
Model 5945: Tin F.P.
Model 5946: Zinc F.P.
Model 5947: Aluminum F.P.
Uncertainty (mK) k=2: 1 Distance from the bottom of the central well to the surface of the pure metal.
“Cell Only”: refers to the expanded uncertainty of the cell when realized by traditional methods and maintained using traditional maintenance devices.
“Simple Realization”: refers to the expanded uncertainty of the cell when realized using practical methods (melting points instead of freezing points or slush ice instead of an ice mantle, for example) and maintained using Hart’s 9210 and 9260 mini cell maintenance apparatus.

Who Needs the Fluke Mini Fixed-Point Cells?

The Fluke Mini Fixed-Point Cells are designed for laboratory and industrial applications where accurate temperature reference is crucial. They are perfect for calibration and testing, and are widely used in various industries.

Fluke Mini Fixed-Point Cells Applications

Use in calibration and testing: The Fluke Mini Fixed-Point Cells are perfect for calibration and testing applications where accurate temperature reference is crucial.
Use in laboratory applications: The Fluke Mini Fixed-Point Cells are widely used in laboratory applications where accurate temperature reference is required.
Use in industrial applications: The Fluke Mini Fixed-Point Cells are designed for industrial applications where accurate temperature reference is crucial.
Use in research and development: The Fluke Mini Fixed-Point Cells are widely used in research and development applications where accurate temperature reference is required.

Why Buy Fluke Mini Fixed-Point Cells from Mohammad Mahdi Electronics?

Mohammad Mahdi Electronics offers a wide range of Fluke Mini Fixed-Point Cells that are designed to provide accurate temperature reference for precise measurements. Our products are of high-quality and are perfect for laboratory and industrial applications.

Fluke Mini Fixed-Point Cells Specifications

Specifications
Model Number	Fixed- Point	Temperature ( °C)	Outside Diameter	Inside Diameter	Total Cell Height	Immersion Depth¹	Cell Only²	Simple Realization²
5901B-G	Water T.P.	0.01	30 mm	8 mm	170 mm	117 mm	0.2	0.5
5914A	Indium F.P.	156.5985	43 mm	8 mm	214 mm	140 mm	1.0	2.0
5915A	Tin F.P.	231.928	43 mm	8 mm	214 mm	140 mm	1.4	3.0
5916A	Zinc F.P.	419.527	43 mm	8 mm	214 mm	140 mm	1.6	4.0
5917A	Aluminum F.P.	660.323	43 mm	8 mm	214 mm	140 mm	4.0	10.0
5918A	Silver F.P.	961.78	43 mm	8 mm	214 mm	140 mm	7.0	n/a
5919A	Copper F.P.	1084.62	43 mm	8 mm	214 mm	140 mm	15.0	n/a
5944	Indium F.P.	156.5985	41.3 mm	7.8 mm	222 mm	156 mm	0.7	1.4
5945	Tin F.P.	231.928	41.3 mm	7.8 mm	222 mm	156 mm	0.8	1.6
5946	Zinc F.P.	419.527	41.3 mm	7.8 mm	222 mm	156 mm	1.0	2.0
5947	Aluminum F.P.	660.323	41.3 mm	7.8 mm	222 mm	156 mm	2.0	4.0
Uncertainty (mK) k=2 ¹Distance from the bottom of the central well to the surface of the pure metal. ²“Cell Only” refers to the expanded uncertainty of the cell when realized by traditional methods and maintained using traditional maintenance devices. “Simple Realization refers to the expanded uncertainty of the cell when realized using practical methods (melting points instead of freezing points or slush ice instead of an ice mantle, for example) and maintained using Hart’s 9210 and 9260 mini cell maintenance apparatus.

Datasheet

Datasheet (PDF)PDF

User Manual

User manual (PDF)PDF
