Description

The Fluke T5-1000 is a versatile and reliable voltage, continuity, and current tester designed for a wide range of applications. With its compact and lightweight design, it is perfect for technicians and engineers who need a reliable tool for their work.

Whether you’re working on electrical systems, testing for continuity, or measuring current, the Fluke T5-1000 has got you covered.

Fluke T5-1000 Key Features

The Fluke T5-1000 features a range of key specifications that make it an ideal choice for professionals.

Jaw opening: 12.9 mm (0.5 in)
Max wire size: 1/0 THHN Cable
Current range AC rms: 0 to 100.0 A
Accuracy AC current (50/60 Hz): 3% ± 3 counts
Voltage range AC/DC: 0 to 1000 V
Resistance range: 0 to 1000 Ω
Continuity beeper threshold: On at 400 Ω
Volts indicator LED threshold: Guaranteed on by 30 V AC

Who Needs the Fluke T5-1000?

The Fluke T5-1000 is designed for technicians and engineers who need a reliable and accurate voltage, continuity, and current tester for their work.

Whether you’re working on electrical systems, testing for continuity, or measuring current, the Fluke T5-1000 is the perfect tool for the job.

Fluke T5-1000 Applications

Electrical system testing: Use the Fluke T5-1000 to test electrical systems and identify any issues.
Continuity testing: Use the Fluke T5-1000 to test for continuity and identify any issues.
Current measurement: Use the Fluke T5-1000 to measure current and identify any issues.
Industrial applications: Use the Fluke T5-1000 in industrial applications where accurate voltage, continuity, and current testing is required.
Commercial applications: Use the Fluke T5-1000 in commercial applications where accurate voltage, continuity, and current testing is required.
Residential applications: Use the Fluke T5-1000 in residential applications where accurate voltage, continuity, and current testing is required.

Why Buy Fluke T5-1000 from Mohammad Mahdi Electronics?

At Mohammad Mahdi Electronics, we offer the Fluke T5-1000 at a competitive price, with a two-year warranty and excellent customer service.

Whether you’re a professional or a DIY enthusiast, the Fluke T5-1000 is the perfect tool for your needs.

Fluke T5-1000 Specifications

Specifications
Jaw opening	12.9 mm (0.5 in)
Max wire size	1/0 THHN Cable
Current range AC rms	0 to 100.0 A
Accuracy AC current (50/60 Hz)	3% ± 3 counts
AC response	Averaging
Voltage range AC/DC	0 to 1000 V
Voltage accuracy
	AC	1.5% ± 2 counts
	DC	1% ± 1 count
Resistance range	0 to 1000 Ω
Continuity beeper threshold	On at 400 Ω
Volts indicator LED threshold	Guaranteed on by 30 V AC
Environmental Specifications
Operating temperature	-10°C to 50°C
Storage temperature	-30°C to 60°C
Humidity (without condensation)
	0% to 95% (5°C to 30°C);
	0% to 75% (30°C to 40°C);
	0% to 45% (40°C to 50°C)
Dust/water resistance	Yes
Operating altitude	2000 meters max
Temperature coefficient	0.1 x (specified accuracy)/°C ( 28°C)
Safety Specifications
Measurement Category	IEC 61010-2-032, IEC61010-2-033: CAT IV 600 V / CAT III 1000 V, 100 A ac
Agency approvals	CSA, TUV
Maximum voltage	1000 V between any terminal and earth ground
Mechanical and General Specifications
Size	30.5 x 51 x 203 mm
Weight	300 g
Warranty	Two-years
Battery life	200 hour zinc chloride, 400 hour alkaline
Battery type	2 x AA
Low battery indicator	Yes
Current sensor opening	12.9 mm

Datasheet

Datasheet (PDF)PDF

User Manual

User manual (PDF)PDF
