Hioki 3481 POWERFUL VOLTAGE DETECTOR

(2 customer reviews)

Short Description:

Hioki VOLTAGE DETECTOR 3481 key features

• Non-contact detection of AC voltage from 40 V to 600 V with bright LED light

• Pen-style, compact detector with pocket clip

• Both visual and audible voltage detection indication

• Meets safety standards for CAT IV 600 V environments

• Prevent dead batteries with battery self-check function and auto power-off function

Product purchase
SKU: 6341 Category:
Brand:Hioki

Call for Best Price In UAE 00971(04) 447 6031 00971(04) 344 9868

11 People watching this product now!
Terms of sending goods ›
  •  In-stock items are delivered within 2 business days.
  • We are not Supporting COD Payments Terms Outside UAE

Hioki VOLTAGE DETECTOR 3481

The Hioki 3481 is a pen-style, non-metallic contact voltage detector with a bright LED light that promotes safety and work efficiency even in dim worksites. When voltage is detected, the LED lights red along with an audio signal.

Hioki 3481 key features

  • Non-contact detection of AC voltage from 40 V to 600 V with bright LED light
  • Pen-style, a compact detector with a pocket clip
  • Both visual and audible voltage detection indication
  • Meets safety standards for CAT IV 600 V environments
  • Prevent dead batteries with battery self-check function and auto power-off function

Hioki 3481 Specifications

  • Measurement function Voltage detection
  • Operating voltage range from 40 V to 600 V AC (When brought into contact with a 2 mm^2 insulated cable equivalent to 600 V polyvinyl chloride insulated wire)
  • Maximum sensitivity variable range from 40 V to 80 V AC (80 V at the time of shipment)
  • Operating voltage range from 40 V to 600 V AC (When brought into contact with a 2 mm^2 insulated cable equivalent to 600 V polyvinyl chloride insulated wire)
  • Maximum sensitivity variable range from 40 V to 80 V AC (80 V at the time of shipment)
  • Operating frequency 50 Hz/ 60 Hz
  • The pilot light Red LED lights up and the buzzer sounds when the wire is live
  • Battery check White LED is dim or out when the batteries are low.
  • Auto power off The power will be turned off automatically if the instrument remains idle for 3 minutes after the power is turned on.
  • Power supply LR44 button alkaline batteries ×3, Continuous use: 5 hr (Power ON standby state)

Related Products

The Hioki 3481-20 is a cutting-edge electrical resistance tester, designed and manufactured by Hioki, a renowned company specializing in electronic test and measurement instruments. Building upon the success of its predecessor, the Hioki 3481, this advanced model offers enhanced features and improved functionality for precise resistance measurements.

datasheet

Data Sheet

Specifications

Voltage Detection Device Technical Specifications
Specification Category Details
Measurement Function Voltage detection
Operating Voltage Range 40 V to 600 V AC (When brought into contact with a 2 mm^2 insulated cable equivalent to 600 V polyvinyl chloride insulated wire)
Maximum Sensitivity Variable Range 40 V to 80 V AC (80 V at the time of shipment)
Operating Frequency 50 Hz/ 60 Hz
Pilot Light Red LED lights up and the buzzer sounds when the wire is live
Battery Check White LED is dim or out when the batteries are low.
Auto Power Off The power will be turned off automatically if the instrument remains idle for 3 minutes after the power is turned on.
Power Supply LR44 button alkaline batteries ×3, Continuous use: 5 hr (Power ON standby state)
Dimensions and Mass 20 mm (0.79 in) W × 126 mm (4.96 in) H × 15 mm (0.59 in) D (excluding projections), 30 g (1.1 oz) (including LR44 button alkaline batteries)
