HIOKI IR4016 insulation resistance testers or megohmmeters feature all-in-one designs including built-in rugged cases and test lead storage compartments. The IR4016-20 is a single-range, 500 V/100 MΩ analog insulation resistance tester with efficient functions and features to help shorten work time associated with field insulation testing.

Hioki IR4016 Specifications:

• Rated output voltage:500 V DC
• Effective maximum indicated value: 100 MΩ
• Lower limit resistance: 0.5 MΩ (measurement resistance value to maintain testing voltage)
• Overload protection: 600 V AC (10 sec.)
• AC voltage range to 600 V (50/60 Hz), ±5 % of maximum scale value accuracy,500 kΩ or more input resistance
• Other functions: Bright LED luminous scale, Drop proof (on concrete, 1 m/1 time), Battery check, Live circuit check, Auto discharge
• Dimensions and mass: 159 mm (6.26 in) W × 177 mm (6.97 in) H × 53 mm (2.09 in) D, 610 g (21.5 oz), (including battery, excluding test lead)
