MadgeTech ETR101A Temperature Data Logger

MadgeTech ETR101A Temperature Data Logger

The ETR101A Includes:
(1) TC101A: Temperature Data Logger
(1) Type K Thermocouple
(1) IFC200: Data Logger Interface
(1) Weatherproof Enclosure
(1) Hex Screwdriver
(1) MadgeTech 4 Software

The MadgeTech ETR101A is a complete system designed to measure the exhaust temperature of road vehicles and off-road equipment. Once the temperature profile is created, it is provided to the Diesel Particulate Filter (DPF) manufacturer to help them select the correct DPF for the exhaust system.

Installation is very simple and easy. Using the MadgeTech 4 software, program the data logger for a certain period of time, then attach the logger (in a waterproof case) to the vehicle. Log data is then retrieved using the IFC200 to upload data to MadgeTech 4 software. Graphical, tabular, and summary data are provided for analysis and can be viewed as technical units with available data. customizable.

To get more information please contact us.

MadgeTech ETR101A Features

•  10 years battery life
•  1-second reading rate
•  Multiple start/stop function
• Ultra high-speed download
• 500,000 readings memory capacity
• Wrap around memory
•  Battery life indicator
•  Optional password protection
• Programmable high and low Alarms
• Field upgradeable

MadgeTech ETR101A Specifications

•  General

• Memory: 1,032,192 readings (all channels enabled)
• Reading Rate: 1 reading every second up to 1 reading every 24 hours
• Baud Rate: 115,200
• Cold Junction Compensation: Automatic
• Channels: 1 Internal & 1 Remote
• LED Indicators: Red and Green
• Battery Life: 10 years typical, dependent upon frequency and duty cycle

• Temperature

• Temperature Sensor: Semiconductor
• Temperature Range: -40 °C to +80 °C (-40 °F to +176 °F)
• Temperature Resolution: 0.1 °C (0.18 °F)
• Temperature Calibrated Accuracy: ±0.25 °C (±0.45 °F)

Accessories

• IFC200
• LTC-7PN Lithium Battery
• Type K 36″ Thermocouple 6″ Sheath
