PCE-DSX 100 Portable LED Stroboscope

The PCE-DSX 100 stroboscope is a convenient tool designed for measuring the speed of objects within a range of 60 to 20,000 RPM. It is particularly useful for inspecting objects with periodic movements and identifying faults. The stroboscope facilitates precise measurements through both fine and coarse adjustment options. Fine adjustment allows for small speed changes: +0.1 RPM for speeds below 1000 RPM and +1 RPM for speeds above 1000 RPM. The coarse setting allows for larger adjustments: +10 RPM for speeds below 1000 RPM and +100 RPM for speeds above 1000 RPM.

Featuring an illuminated LC display with a 16 mm digit height, the stroboscope offers clear visibility even in low-light environments. Its flash light source, comprised of over 36 LEDs, produces bright flashes of light for precise measurements. Automatic shut-off after 5 minutes of inactivity conserves energy and prolongs battery life. The stroboscope includes a memory function for storing up to 10 flash frequencies, enabling quick switching between different settings. Additionally, it provides automatic alerts when the supply voltage is insufficient, ensuring smooth and trouble-free operation.

PCE-DSX 100 Key Features

Measuring range from 60 … 20000 RPM
Automatic switch-off
2.1″ LC display with illumination
Data storage function for up to 10 values
Coarse adjustment in steps, +10, +100 RPM
Fine adjustment in steps, +0.1, +1 RPM

PCE-DSX 100 Specifications

Visual speed
Measuring range	60 RPM … 999.9 RPM
Resolution	0.1 RPM
Accuracy	0.05%
Visual speed
Measuring range	1000 RPM … 20000 RPM
Resolution	1 RPM
Accuracy	0.05%
General technical data
Display type	LCD with illumination
Display size	2.1 inch
Storage medium	Internal memory
Memory capacity	10 values
Automatic switch-off	5 min
Light intensity	approx. 1400 lx @20cm @10000 RPM
Light source	36 LED’s
Menu language	English
Protection class (device)	IP20
Weight	180 g
Dimensions (L x W x H)	180 x 68 x 56 mm
Operating conditions	0 … 50 °C , 10 … 85 % r.H
Storage conditions	0 … 50 °C , 10 … 85 % r.H
