PCE-360 Single/ Three Phase Power Logger

PCE-360 Single/ Three Phase Power Logger

Single-Phase Power Meter PCE-360 or clamp meter with data logger functionality. This versatile power analyzer can take single-phase and three-phase power measurements both in real time and over an extended time period. The PCE-360 is used for the analysis of voltage (V), current (A), active power (kW), apparent power (kVA), reactive power (kVar), power factor (cos Φ), phase angle (Φ), frequency (Hz), rotary field (UL > 50V), active energy (MWh), apparent energy (MVAh), reactive energy (MVArh), harmonics (1 … 63 order, via software), and waveforms (via software).

The meter’s large and easy-to-examine display presentations up to 10 measurements simultaneously. In guide mode, the tool shops as much as 99 measurements directly. In statistics logger mode, the tool shops up to 10,000,000 units of measurements to the 4 GB inner memory. Measured values are transferred without difficulty to a PC the usage of the covered Windows-well suited software program and statistics cable. In addition, 4 modern-day clamps, 4 alligator clips, and 4 measuring leads are covered withinside the shipping contents.

features

• For measurement in real-time and over an extended time period up to 578 days @ 5-second sample rate
• Includes clamps, clips, leads, PC software, and data cable
• A large, easy-to-read screen displays up to 10 measurements simultaneously
• Stores up to 99 measurements directly in manual mode or up to 10,000,000 sets of measurements to the 4 GB internal memory in data logger mode
• Battery-saving automatic shutdown after approximately 30 minutes of inactivity
• The device comes factory calibrated – optional ISO calibration certificate available for an additional fee (see accessories for details)

Single-Phase Power Meter PCE-360 specifications:

• AC Voltage measurement 50-600.0 V True RMS value
• Accuracy ±1.5 % of measured value
• Resolution +10 digits / 0.1 V
• AC Current measurement 3 … 999.9 A True RMS value
• Accuracy ±1.5 % of measured value
• Resolution +15 digits / 0.1 A
• Active Power measurement P 150 W- 999.9 kW
• Accuracy ±1.5 % of measured value
• Resolution +20 digits / 0.1 KW
• Apparent Power measurement S 150 VA… 999.9 kVA
• Accuracy ±1.5 % of measured value
• Resolution +20 digits / 0.1 KVA
• Reactive Power measurement Q 150 VAR… 999.9 kVar
• Accuracy ±1.5 % of measured value
• Resolution +20 digits / 0.1 KVar
• Power Factor measurement 0 … +1 COSψ
• Accuracy ± 0.06
• Resolution 0.001
• Frequency measurement (U > 50V) 40 … 100 Hz
• Accuracy ±1 % of measured value +2 digits
• Resolution 0.1 Hz
• Display illuminated LC display
• Power supply 8 x 1.5 V type AA (Mignon)
• Dimensions 235 x 117 x 54 mm
• Weight 730 g
