Testo 160 IAQ – WiFi Data Logger

Testo 160 IAQ – WiFi Data Logger With Display and Integrated Sensors For Temperature, Humidity, CO₂ and Atmospheric Pressure

Order-Nr.  0572 2014

Indoor air quality has a huge influence on people’s health and well-being. Stale indoor air can lead to tiredness, loss of concentration and discomfort. Reliable monitoring of indoor air quality with the WiFi data logger testo 160 IAQ. The data logger can for example be used in schools, nursery schools, conference rooms, open-plan offices, auditoriums or museums – in short: in rooms where a lot of people gather.

Testo 160 IAQ – WiFi Data Logger With Display and Integrated Sensors For Temperature, Humidity, CO₂ and Atmospheric Pressure Specifications:

Humidity – Capacitive

• Measuring range : 0 to 100 %RH (non-condensing)
• Accuracy :

• ±2.0 %RH at +25 °C and 20 to 80 %RH
• ±3.0 %RH at +25 °C and < 20 and > 80 %RH
• ±1.0 %RH hysteresis
• ±1.0 %RH / year drift

• Resolution: 0.1 %RH

Absolute Pressure

• Measuring range: 600 to 1100 mbar
• Accuracy : ±3 mbar at +22 °C
• Resolution: 1 mbar

Ambient CO₂

• Measuring range :0 to 5000 ppm
• Ambient humidity: 0 to 99 %RH (non-condensing)
• Accuracy :

• ±(50 ppm + 3 % of mv) at 25 °C
• Without external power supply:
• ±(100 ppm + 3 % of mv) at 25 °C

• Resolution: 1 ppm

Temperature

• Measuring range : 0 to +50 °C
• Accuracy: ±0.5 °C
• Resolution: 0.1 °C

General technical data

• Weight: 269 g
• Dimensions : 117 x 82 x 32 mm ((LxWxH))
• Operating temperature : 0 to +50 °C
• Product-/housing material: PC – ABS
• Protection class: IP20
• Product colour: white
• Measuring rate: Dependent on Cloud licence; Basic: 15 min … 24 h / Advanced: 1 min … 24 h
• Communication rate: Dependent on Cloud licence; Basic: 15 min … 24 h / Advanced: 1 min … 24 h
• WLAN Connectivity : supported wireless LAN standards: IEEE 802.11 b/g/n and IEEE 802.1X; Possible encryption methods: WPA2 Enterprise: EAP-TLS, EAP-TTLS-TLS, EAP-TTLS-MSCHAPv2, EAP-TTLS-PSK, EAP-PEAP0-TLS, EAP-PEAP0-MSCHAPv2, EAP-PEAP0-PSK, EAP-PEAP1-TLS, EAP-PEAP1-MSCHAPv2, EAP-PEAP1-PSK, WPA Personal, WPA2 (AES), WPA (TKIP), WEP
• Alarm function: LED (traffic light function: red, yellow, green)
• Battery life: 1 year
• Display type: LCD (Liquid Crystal Display)
• Power supply: 4 x AA batteries 1.5 V, alternatively mains unit via USB connection
• Interface: USB
• Radio range: 100 m
• Memory: 32,000 Measuring values / Sum of all channels
• Storage temperature : 0 to +50 °C
• Dimension display : 55 x 42 mm
