Description

Fluke-718 300G Key Features

Technical Specifications
Fluke 718 Series
Measure pressure: (Internal sensor)
Accuracy: 0.025% full scale
Functions: Zero, min/max, hold, damp
Dry air, non-corrosives only
Fluke 718 1G
Range: -1 psi to +1 psi, -68.9 mbar to 68.9 mbar (-6.89 kPa to 6.89 kPa)

Who Needs the Fluke-718 300G?

Field technicians search for a dependable Fluke-718 300G when troubleshooting HVAC, electrical, or industrial systems. Engineers look up model-level specs before specifying instruments on drawings. Maintenance teams compare kits and accessories. Buyers searching “buy Fluke-718 300G” or “Fluke-718 300G UAE” use this listing to confirm the correct SKU and request pricing from MME.

Fluke-718 300G Applications

Use the Fluke-718 300G in commissioning, preventive maintenance, diagnostics, and acceptance testing where accurate measurements matter. Match the instrument to your category and environment using only the published specifications on this page.

Why Buy Fluke-718 300G from MME?

MME supplies measurement and test equipment across the UAE with product pages that keep brand, model, and SKU accurate. Request a quote for the Fluke-718 300G and related accessories from mme-ae.com.

Fluke-718 300G Specifications

Technical Specifications
Fluke 718 Series
Measure pressure	(Internal sensor)
Accuracy	0.025% full scale
Functions	Zero, min/max, hold, damp
Dry air, non-corrosives only
Fluke 718 1G
Range	-1 psi to +1 psi, -68.9 mbar to 68.9 mbar (-6.89 kPa to 6.89 kPa)
Resolution	0.0001 psi, 0.001 mbar, 0.0001 kPa
Over pressure	5x Full Scale
Functions	Zero, Min, Max, Hold, Damp
Fluke 718 30G
Range	-12 psi to 30 psi, (-850 mbar to 2 bar, -85 to 206.84 kPa)
Resolution	0.001 psi, 0.1 mbar, 0.01 kPa
Over pressure	5x Full Scale
Functions	Zero, Min, Max, Hold, Damp
Fluke 718 100G
Range	-12 psi to 100 psi, (-850 mbar to 7 bar, -85 to 689.48 kPa)
Resolution	0.01 psi, 0.1 mbar, 0.01 kPa
Over pressure	2x Full Scale
Functions	Zero, Min, Max, Hold, Damp
Fluke 718 300G
Range	-12 psi to 300 psi, (-850 mbar to 20 bar, -85 to 2068.42 kPa)
Resolution	0.01 psi, 1 mbar, 0.1 kPa
Over pressure	375 psi 25 bar
Functions	Zero, Min, Max, Hold, Damp
Fluke 718 series via 700 Series Pressure Modules
Range	29 pressure modules, 0 – 1 inH₂0 to 10,000 psi, 2.5 mbar to 700 bar. Over pressure per pressure module specs
Resolution	Per pressure module specs
Accuracy	To 0.025% of full span, per pressure module specs
Functions	Zero, Min, Max, Hold, Damp
Media compatibility per pressure module specs
Fluke 718 Series Via Built in Pump
Range	-12 psi or -850 mbar to full scale Supported Pressure Units; psi, inH₂0 (4°C), inH₂0 (20°C), cmH₂0 (4°C), cmH₂0 (20°C), bar, mbar, kPa, inHg, mmHg, kg/cm
Loop power range	24 V DC
Accuracy	±10%
Drive; 20 mA into 1000 Ω for battery > 6.8 V; 700 Ω for battery 5.8 to 6.8 V
mA Measure
Range	0 mA to 24 mA
Resolution	0.001 mA
Accuracy	0.015% + 1 count
General Specifications
Maximum voltage	30 volts (non-operating)
Temperature	-40°C to 60°C
Operating temperature	-10°C to 55°C
Relative humidity	95% (10°C to 30°C); 75% (30°C to 40°C); 45% (40°C to 50°C); 35% (50°C to 55°C)
Operating altitude	3,000 M max
Shock	1 M drop test
Vibration	Random, 2 g, 5 Hz – 500 Hz
Safety	CSA C22.2 No. 1010.1: 1992
EMC	EN50082-1: 1992 and EN55022: 1994 Class B
Size	216 x 94 x 66 mm (8.50 x 3.72 x 2.60 in)
Weight	992 g (35 oz)
Power, battery life	9V battery ANSI/NEDA 1604A or IEC 6LR619V alkaline; two batteries in 718
Battery life	4 to 20 hours typical, depending on functions used
Warranty	Three years (one year on pressure pump in Fluke 718)
Display	LCD, 5 digit pressure and current simultaneous
For use with non-corrosive gasses
