Description

The Fluke Calibration P3100 Hydraulic Deadweight Testers are designed to provide accurate pressure measurements in a variety of applications. With oil operated ranges up to 20,000 psi (1400 bar) and ±0.015% of reading accuracy (±0.008% optional), these testers are ideal for pressure testing and calibration.

Fluke Calibration P3100 Hydraulic Deadweight Testers Key Features

The Fluke Calibration P3100 Hydraulic Deadweight Testers feature a range of key specifications, including:

Pressure Ranges: Up to 20,000 psi (1400 bar)
Accuracy: ±0.015% of reading (±0.008% optional)
Materials of Construction: Standard weight material: Series 3 non-magnetic austenitic stainless steel
Optional Fractional Weights: Solution heat treated aluminum
PressCal Software: Windows-based software program for easy calibration and correction

Who Needs the Fluke Calibration P3100 Hydraulic Deadweight Testers?

The Fluke Calibration P3100 Hydraulic Deadweight Testers are designed for use in a variety of applications, including pressure testing and calibration. These testers are ideal for technicians and engineers who need accurate and reliable pressure measurements.

Fluke Calibration P3100 Hydraulic Deadweight Testers Applications

Pressure Testing: The Fluke Calibration P3100 Hydraulic Deadweight Testers are ideal for pressure testing a wide range of applications, including hydraulic systems and pressure vessels.
Calibration: The testers are also suitable for calibration purposes, providing accurate and reliable pressure measurements.
Research and Development: The testers can be used in research and development applications, where accurate pressure measurements are required.
Quality Control: The testers are also suitable for quality control purposes, providing accurate and reliable pressure measurements to ensure product quality.

Why Buy Fluke Calibration P3100 Hydraulic Deadweight Testers from MME?

The Fluke Calibration P3100 Hydraulic Deadweight Testers are available from MME, a leading supplier of calibration equipment. With a wide range of applications and a reputation for reliability and accuracy, these testers are the ideal choice for technicians and engineers who need accurate and reliable pressure measurements.

Fluke Calibration P3100 Hydraulic Deadweight Testers Specifications

Pressure Ranges
Oil operated	Ranges to 20,000 psi (1400 bar)
Accuracy
Accuracy¹	±0.015% of reading (±0.008% optional)
1. Accuracy based on % of reading from 10% to 100% of the piston range when used in accordance with the corrections found on the calibration certificate. Below 10% ± (accuracy class) x 10% of the piston range.
Materials of Construction
Standard weight material	Series 3 non-magnetic austenitic stainless steel
Weight density	7.8 g/cm³
Optional fractional weights	Solution heat treated aluminum
Weight density	2.7 g/cm³
Piston material	Tungsten carbide with nickel binder Density- 15.0 g/cm³
Cylinder material	Hardened martensitic steel Tungsten carbide (water above 500 psi, 35 bar)
Thermal coefficients of expansion	Oil piston/cylinder 16.5 ppm/°C Water (above 500 psi, 35 bar) 11 ppm/°C
General
Test port adaptors	1/8, 1/4, 3/8 and ½ NPT or BSP
Instrument weight	36 lbs (16 kg)
Instrument size (W x D x H)	17.5 x 12 x 8.5
Mass set weight (typical)	80 lbs (36 kg)
Reservoir volume	150 cc
Screw press displacement	5.5 cc
Pump displacement	4.7 cc per stroke
O-ring seal materials	Buna N as standard, Viton and EPDM available
Weight Increments
Minimum standard weight increments	Up to 500 psi (35 bar): 1 psi (0.1 bar) 500 to 5000 psi (35 to 350 bar): 10 psi (1 bar) 5000 to 20,000 psi (350 to 1400 bar): 20 psi (2 bar) Model P3112: 1 psi (0.1 bar)
Optional fractional weights	Up to 500 psi (35 bar): 0.1 psi (0.01 bar) 500 to 5000 psi (35 to 350 bar): 1 psi (0.1 bar) 5000 to 20,000 psi (350 to 1400 bar): 2 psi (0.2 bar)
Operating Fluid
Mineral oil	Shell spindle oil 22, our reference 55-655, viscosity 40 cs @ 20°C
Options
PressCal software	Windows-based software program that allows users to easily apply all necessary corrections to enhance the deadweight tester performance. Calibration details are then stored and/or used to automatically create a calibration certificate. PressCal is provided as standard with all 0.008% instruments.
Fluids	Instruments can be supplied for use with Skydrol or brake fluids. Due to the aggressive nature of these fluids the standard nitrile seals and the acrylic reservoir tube will be replaced by either Viton or EPDM seals (as applicable) and an aluminum reservoir tube. For these or any other specialty fluid applications, please consult the factory.
