Description

The Fluke FLK‑TIS75+ Thermal Camera 9HZ delivers high‑resolution infrared imaging for professionals who demand reliable temperature measurements in challenging environments. Built on Fluke’s renowned engineering, this compact, rugged camera offers a 9 Hz frame rate, a wide spectral band of ~8‑14 µm, and a versatile set of user‑defined markers and boxes. Whether you’re inspecting electrical panels, HVAC systems, or industrial equipment, the FLK‑TIS75+ provides precise data and intuitive controls in a single, portable package.

Fluke FLK-TIS75+ 9HZ Key Features

Color alarms for hot and cold points with user‑selectable ranges
Infrared spectral band of ~8‑14 µm
Operating temperature –10 °C to 50 °C (14 °F to 122 °F)
Storage temperature –20 °C to 50 °C without batteries
Five user‑adjustable spot markers and measurement boxes with min, max, and average statistics
Hard, IP54‑rated case with soft transport bag and adjustable strap
Weight (battery included) ≤2.27 kg (5 lb)
Two‑year warranty and recommended calibration cycle

Fluke FLK-TIS75+ 9HZ Who Needs the FLK-TIS75+ 9HZ?

Engineers, field technicians, and maintenance teams working in industrial, electrical, and HVAC sectors rely on the FLK‑TIS75+ for rapid, non‑contact temperature assessments. Its rugged construction, IP54 rating, and 9 Hz frame rate make it ideal for environments with vibration, shock, or dust. Buyers comparing thermal cameras will appreciate the device’s dual‑year warranty, extensive language support, and compliance with IEC, FCC, and Australian RCM standards.

Fluke FLK-TIS75+ 9HZ Applications

The FLK‑TIS75+ is suited for inspecting electrical panels, motor bearings, heat‑seal integrity, HVAC components, and any system where temperature anomalies can indicate failure or inefficiency. Its user‑defined markers and boxes enable precise spot and area measurements, while the color alarms provide immediate visual cues for critical thresholds.

Fluke FLK-TIS75+ 9HZ Why Buy FLK-TIS75+ 9HZ from MME?

MME offers expert support, comprehensive after‑sales service, and a dedicated team familiar with Fluke’s product line. By purchasing through MME, you gain access to local technical assistance, rapid delivery, and MME for all your measurement and test equipment needs.

Fluke FLK-TIS75+ 9HZ Specifications

General specifications
Color alarms	Yes. User-selectable hot and cold point and internal/external range color alarms. Modifies palettization of IR image by limiting which pixels are drawn using palette colors based on the pixel temperature.
Infrared spectral band	~8-14μm
Operating temperature	-10 °C to 50 °C (14 °F to 122 °F)
Storage temperature	-20 °C to 50 °C (-4 °F to 122 °F) without batteries
Relative humidity	10 % to 95 % non-condensing
Spot temperature	Center spot (unmovable)
User-definable spot markers	Yes, 5 user-adjustable spot markers for a single pixel each. Position is adjustable. Temperature value for marker shown on screen. User can choose to switch display on/off for each marker.
User defined measurement boxes	Yes, 5 user-adjustable rectangles. Size and position are adjustable. Rectangle statistics shown on screen: Min, Max, Average temperature. User can choose to switch display on/off for each marker.
Hard case	Rugged hard carrying case with soft transport bag, including adjustable strap
Safety standards	IEC 61010-1: Pollution Degree 2
Electromagnetic combability	IEC 61326-1: Portable Electromagnetic Environment; IEC 61326-2-2 CISPR 11: Group 1, Class A
Australian RCM	RCM IEC 61326-1
US FCC	47 CFR 15 Subpart C Sections 15.207, 15.209, 15.249
Vibration	10 Hz to 150 Hz, 0.15 mm, IEC 60068-2-6
Shock	30 g, 11 ms, IEC 60068-2-27
Drop	Engineered to withstand 2m drop
Sized (H x W x L)	∼(26.7 cm x 10.1 cm x 14.5 cm) ∼ (10.5 in x 4.0 in x 5.7 in)
Weight (battery included)	≤2.27 kg (5 lb)
Enclosure rating	IP54
Warranty	Two-years (standard)
Recommended calibration cycle	Two-years (assumes normal operation and normal aging)
Supported languages	Czech, Dutch, English, Finnish, French, German, Hungarian, Italian, Japanese, Korean, Polish, Portuguese, Russian, Simplified Chinese, Spanish, Swedish, Traditional Chinese, and Turkish
RoHS compliant	Yes
