Fluke t3000 FC Wireless Temperature Kit

The Fluke t3000 FC Wireless Temperature Kit is a reliable and accurate solution for temperature measurement in industrial applications. With its ±0.5°C resolution, this kit provides precise readings in a variety of environments.

Whether you’re working in a factory, laboratory, or construction site, the Fluke t3000 FC Wireless Temperature Kit is designed to withstand harsh conditions and provide reliable results.

Fluke t3000 FC Wireless Temperature Kit Key Features

The Fluke t3000 FC Wireless Temperature Kit features a range of advanced technologies, including wireless connectivity, long battery life, and a compact design.

• Wireless connectivity for easy data transfer
• Long battery life of 250 hours
• Compact and rugged design for harsh environments
• Meets IEC 61010-1 safety standards
• Compliant with RoHS and WEEE regulations

Who Needs the Fluke t3000 FC Wireless Temperature Kit?

The Fluke t3000 FC Wireless Temperature Kit is designed for use in a variety of industrial applications, including:

Factory and manufacturing environments

Construction sites

Laboratories and research facilities

Power plants and utilities

Any environment where accurate temperature measurement is critical

Fluke t3000 FC Wireless Temperature Kit Applications

• Temperature monitoring in industrial processes
• Quality control in manufacturing environments
• Research and development in laboratories and research facilities
• Power plant operations and utilities
• Construction site monitoring and quality control

Why Buy Fluke t3000 FC Wireless Temperature Kit from mme-ae?

The Fluke t3000 FC Wireless Temperature Kit is a reliable and accurate solution for temperature measurement in industrial applications. With its advanced features and rugged design, this kit is perfect for use in harsh environments.

At Mohammad Mahdi Electronics, we offer a wide range of industrial measurement solutions, including the Fluke t3000 FC Wireless Temperature Kit. Our experienced team is dedicated to providing exceptional customer service and support.

Fluke t3000 FC Wireless Temperature Kit Specifications

AC Voltage
Range 1	Resolution	Accuracy 2 3 4		Accuracy 2 3 4
		45 Hz to 500 Hz		500 Hz to 1 kHz
600.0 mV	0.1 mV	1.0% + 3		2.0% + 3
6.000 V	0.001 V
60.00 V	0.01 V
600.0 V	0.1 V
1000 V	1 V
1. All AC voltage ranges are specified from 1% of range to 100% of range. 2. Crest factor of ≤ 3 at full scale up to 500 V, decreasing linearly to crest factor < 1.5 at 1000 V. 3. For non-sinusoidial waveforms, add ±(2% of reading + 2% full scale) typical, for crest factor up to 3. 4. Do not exceed 107 V-Hz.
DC Voltage, Continuity, Resistance, Diode Test and Capacitance
Function	Range	Resolution		Accuracy
mV	600.0 mV	0.1 mV		0.09% + 2
V	6.000 V	0.001 V		0.09% + 2
	60.00 V	0.01 V
	600.0 V	0.1 V
	1000 V	1 V		0.15% + 2
Ω	600 Ω	1 Ω		Meter beeps at < 25 Ω, beeper detects opens or shorts of 250 μs or longer.
Ω	600.0 Ω	0.1 Ω		0.5% + 2
	6.000 kΩ	0.001 kΩ		0.5% + 1
	60.00 kΩ	0.01 kΩ
	60.00 kΩ	0.1 kΩ
	600.0 kΩ	0.001 MΩ
	50.00 MΩ	0.01 MΩ		1.5% + 3
Diode test	2.000 V	0.001 V		1% + 2
µF	1000 nF	1 nF		1.2% + 2
	10.00 μF	0.01 μF
	100.0 μF	0.1 μF
	9999 μF1	1 μF		10% typical
1. In the 9999 μF range for measurements to 1000 μF, the measurement accuracy is 1.2% + 2.
AC and DC Current
Function	Range 1	Resolution		Accuracy
mA AC (45 Hz to 1 kHz)	60.00 mA	0.01 mA		1.5% + 3
	400.0 mA 3	0.1 mA
mA DC 2	60.00 mA	0.01 mA		0.5% + 3
	400.0 mA 3	0.1 mA
1. All AC current ranges are specified from 5% of range to 100% of range. 2. Input burden voltage (typical): 400 mA input 2 mV/mA. 3. 400.0 mA accuracy specified up to 600 mA overload.
Frequency
Range	Resolution		Accuracy 1
99.99 Hz	0.01 Hz		0.1% + 1
999.9 Hz	0.1 Hz
9.999 kHz	0.001 kHz
99.99 kHz	0.01 kHz
1. Frequency is specified up to 99.99 kHz in volts and up to 10 kHz in amps.
Input Characteristics
Function	Overload protection	Input impedance (nominal)	Common mode rejection ratio (1 kΩ unbalance)		Normal mode rejection
	1100 Vrms	> 10 MΩ < 100 pF	> 120 dB at DC, 50 Hz or 60 Hz		> 60 dB at 50 Hz or 60 Hz
	1100 Vrms	> 10 MΩ < 100 pF	> 60 dB, DC to 60 Hz
	1100 Vrms	> 10 MΩ < 100 pF	> 120 dB at DC, 50 Hz or 60 Hz		> 60 dB at 50 Hz or 60 Hz
Open circuit test voltage			Full scale voltage		Typical short circuit current
			To 6 MΩ	50 MΩ
	1100 V RMS	< 2.7 VDC	< 0.7 VDC	< 0.9 VDC	< 350 mA
	1100 Vrms	< 2.7 VDC	2.000 VDC		< 1.1 mA
mA Function
Overload Protection	Fused, 44/100 A, 1000 V FAST Fuse
Overload	600 mA overload for 2 minutes maximum, 10 minutes rest minimum
MIN/MAX Recording Accuracy
DC functions	The specified accuracy of the measurement function ± 12 counts for changes > 350 mS in duration.
AC functions	The specified accuracy of the measurement function ± 40 counts for changes > 900 mS in duration.
General Specifications
Maximum voltage between any terminal and earth ground	1000 VDC or AC rms
Ω fuse protection from A inputs	0.44 A (44/100 A, 440 mA), 1000 V FAST Fuse, Fluke specified part only
Display (LCD)	Update rate		4/sec
	Volts, amps, ohms		6000 counts
	Frequency		10,000 counts
	Capacitance	1,000 counts
Battery type	Three AA Alkaline batteries, NEDA 15A IEC LR6
Battery life	250 hours minimum
RF communications	2.4 GHZ ISM Band
RF communication range	Open air, unobstructed		Up to 20 m
	Obstructed, sheetrock wall		Up to 6.5 m
	Obstructed, concrete wall, or steel electrical enclosure		Up to 3.5 m
Temperature	Operating	-10°C to 50°C
	Storage	-40°C to 60°C
Temperature coefficient	0.1 x (specified accuracy) / °C ( 28°C)
Relative humidity	0% to 90% (0°C to 35°C) 0% to 75% (35°C to 40°C) 0% to 45% (40°C to 50°C)
Altitude	Operating		2,000 m
	Storage		12,000 m
Electromagnetic compatibility EMI, RFI, EMC, RF	EN 61326-1:2006, EN 61326-2-2:2006 ETSI EN 300 328 V1.7.1:2006, ETSI EN 300 489 V1.8.1:2008, FCC Part 15 Subpart C Sections 15.207, 15.209, 15.249 FCCID : FCC: T68-FDMMBLE IC: 6627A-FDMMBLE
Safety compliance	ANSI/ISA 61010-1 / (82.02.01)		3rd edition
	CAN/CSA-C22.2 No 61010-1-12		3rd edition
	UL 61010-1		3rd edition
	IEC/EN 61010-1		2010
Certifications	CSA, FCC, CE
Ingress Protection (IP) rating	IP54
Pollution degree	2
Size (H x W x L)	4.75 x 9.3 x 20.7 cm (1.87 x 3.68 x 8.14 in)
Weight	340 g (12 oz)
Warranty	Three years
Not compatible with Fluke CNX test tools
