Description

The Fluke TiS40 Infrared Camera is a powerful tool for thermal imaging and temperature measurement. With its high-resolution detector and advanced IR-Fusion Technology, this camera delivers precise temperature measurements and enhanced image quality.

Whether you’re working in a industrial or commercial setting, the Fluke TiS40 is designed to withstand the rigors of the job site, with a ruggedized design and extensive SD memory system.

Fluke TiS40 Key Features

The Fluke TiS40 Infrared Camera features a range of advanced technologies, including:

IFOV (spatial resolution): 3.9 mRad
Detector resolution: 160×120
Field of view: 35.7 ° x 26.8 °
Distance to spot: 257:1
Wireless connectivity: Yes
Fluke Connect app compatibility: Yes (where available)
IR-Fusion Technology: AutoBlend mode with 5 presets (0%, 25%, 50%, 75%, 100%)
Picture-In-Picture (PIP): 5 presets (0%, 25%, 50%, 75%, 100%)
Focus system: Fixed focus, Minimum focus distance 0.45 m (1.5 ft)
Ruggedized display: 3.5 inch (landscape) 320×240 LCD
Rugged, ergonomic design for one-handed use: Yes

Who Needs the Fluke TiS40?

The Fluke TiS40 Infrared Camera is designed for professionals who require precise temperature measurement and thermal imaging. This includes:

Industrial maintenance technicians

Facilities managers

Building inspectors

Electrical engineers

And anyone who needs to measure temperature and detect heat leaks in a variety of settings.

Fluke TiS40 Applications

Use case: Detecting heat leaks in buildings and homes
Use case: Inspecting electrical equipment and circuits
Use case: Measuring temperature in industrial processes
Use case: Detecting moisture and water damage
Use case: Inspecting HVAC systems and ductwork
Use case: Measuring temperature in food processing and storage

Why Buy Fluke TiS40 from MME?

The Fluke TiS40 Infrared Camera is a powerful tool for thermal imaging and temperature measurement. At MME, we offer competitive pricing and expert support to ensure that you get the most out of your investment.

Fluke TiS40 Specifications

Key Features
IFOV (spatial resolution)	3.9 mRad
Detector resolution	160×120
Field of view	35.7 ° x 26.8 °
Distance to spot	257:1
Wireless connectivity	Yes
Fluke Connect^® app compatible	Yes (where available)
IR-Fusion® Technology
AutoBlend™ mode	5 presets (0%, 25%, 50%, 75%, 100%)
Picture-In-Picture (PIP)	5 presets (0%, 25%, 50%, 75%, 100%)
Focus system	Fixed focus, Minimum focus distance 0.45 m (1.5 ft)
Ruggedized display	3.5 inch (landscape) 320×240 LCD
Rugged, ergonomic design for one-handed use	Yes
Thermal sensitivity (NETD)	≤0.09 °C at 30 °C target temp (90 mK)
Temperature measurement range (not calibrated below -10 °C)	-20 °C to +350 °C (–4 °F to 662 °F)
Level and span	Smooth auto and manual scaling
Fast auto toggle between manual and auto modes	Yes
Fast auto-rescale in manual mode	Yes
Minimum span (manual mode)	2.5 °C
Minimum span (auto mode)	5 °C
Built-in digital camera (visible light)	5 MP
Frame rate	9 Hz
Laser pointer	–
Data storage and Image Capture
Extensive SD memory system	Internal 4 GB (optional 4 GB micro SD card sold separately)
Image capture, review, save mechanism	One-handed image capture, review, and save capability
Image file formats	Non-radiometric (.bmp) or (.jpeg) or fully-radiometric (.is2); No analysis software required for non-radiometric (.bmp, .jpg) files
Instant Upload	Instantly upload captured images to Fluke Connect server with the use of a WiFi connection
Memory review	Thumbnail review
Software	SmartView® software – full analysis and reporting software and Fluke Connect^® (where available)
Export file formats with SmartView® software	BMP, DIB, GIF, JPE, JFIF, JPEG, JPG, PNG, TIF, and TIFF
Voice annotation	–
IR-PhotoNotes™	–
Standard video recording	–
Radiometric video recording	–
Video file formats	–
Streaming video (remote display)	–
Battery
Batteries (field-replaceable, rechargeable)	One lithium ion smart battery pack with five-segment LED display to show charge level
Battery life	Four+ hours
Battery charge time	2.5 hours to full charge
Battery charging system	In-imager charging (optional external charger sold separately)
AC operation	AC operation with included power supply (100 V AC to 240 V AC, 50/60 Hz)
Temperature Measurement
Accuracy	±2 °C or 2% (at 25 °C nominal, whichever is greater)
On-screen emissivity correction	Yes (both value and table)
On-screen reflected background temperature compensation	Yes
On-screen transmission correction	Yes
Color Palettes
Standard palettes	7: Ironbow, Blue-Red, High-Contrast, Amber, Amber Inverted, Hot Metal, Grayscale, Grayscale Inverted
Ultra Contrast™ palettes	–
General Specifications
Color alarms (temperature alarms)	High temperature, low temperature
Infrared spectral band	7.5 μm to 14 μm
Operating temperature	-10 °C to +50 °C (14 °F to 122 °F)
Storage temperature	-20 °C to +50 °C (-4 °F to 122 °F)
Relative humidity	10% to 95%, non-condensing
Center-point temperature measurement	–
Spot temperature	Yes
User-definable spot markers	1
Center box	–
Safety standards	EN 61010-1: CAT none, pollution degree 2, EN 60825-1: Class 2, EN 60529, EN 62133 (lithium battery)
Electromagnetic compatibility	EN 61326-1:2006, EN 55011: Class A, EN 61000-4-2, EN 61000-4-3
C Tick	IEC/EN 61326-1
US FCC	EN61326-1; FCC Part 5, EN 55011: Class A, EN 61000-4-2, EN 61000-4-3
Vibration and shock	2G, IEC 68-2-6 and 25G, IEC 68-2-29
Drop	Engineered to withstand 2 m (6.5 ft) drop
Size (H x W x L)	26.7 x 10.1 x 14.5 cm (10.5 x 4.0 x 5.7 in)
Weight (battery included)	Fixed focus .72 kg (1.6 lb), Manual focus .77 kg (1.7 lb)
Enclosure rating	IP54 (protected against dust, limited ingress; protection against water spray from all directions)
Warranty	Two-years (standard), extended warranties are available
Recommended calibration cycle	Two-years (assumes normal operation and normal aging)
Supported languages	Czech, Dutch, English, Finnish, French, German, Hungarian, Italian, Japanese, Korean, Polish, Portuguese, Russian, Simplified Chinese, Spanish, Swedish, Traditional Chinese, and Turkish
