Description

The Fluke v3000 FC Wireless AC Voltage Module is a cutting-edge solution for measuring AC voltage in various applications. With its wireless capabilities, this module offers unparalleled flexibility and convenience.

Whether you’re working on electrical panels, motors, or other equipment, the v3000 FC provides accurate and reliable measurements, making it an essential tool for technicians and engineers.

Fluke v3000 Key Features

The v3000 FC boasts an impressive range of features, including:

6.000 V to 1000 V measurement range
2.4 GHz ISM band RF communication
Up to 6.5 m open-air communication range
400 hour battery life
Three-year warranty

Who Needs the Fluke v3000?

The v3000 FC is designed for professionals who require accurate and reliable AC voltage measurements. Whether you’re working in electrical maintenance, industrial automation, or other fields, this module is an essential tool for your toolkit.

Fluke v3000 Applications

Electrical panel testing
Motor testing and maintenance
Power quality analysis
Electrical safety testing
Industrial automation

Why Buy Fluke v3000 from mme-ae?

At mme-ae, we offer the Fluke v3000 FC Wireless AC Voltage Module at competitive prices, along with exceptional customer service and support. Whether you’re a seasoned professional or just starting out, we’re here to help you find the right tools for your needs.

Fluke v3000 Specifications

Specifications
Range¹ / Resolution	6.000 V / 0.001 V 60.00 V / 0.01 V 600.0 V / 0.1 V 1000 V / 1 V
Accuracy²³⁴	45 Hz to 500 Hz	1.0% + 3
	500 Hz to 1 kHz	2.0% + 3
Accuracy is specified as ± ([% of reading] + [number of least significant digits]). All ranges are autoranging. Accuracy is specified from 5% to 100% of the range obtained by autoranging, from 18°C to 28°C. 1. All AC voltage ranges are specified from 1% of range to 100% of range. 2. Crest factor of ≤ 3 at full scale up to 500 V, decreasing linearly to crest factor < 1.5 at 1000 V. 3. For non-sinusoidial waveforms, add ± (2% of reading + 2% full scale) typical, for crest factor up to 3. 4. Do not exceed 107 V-Hz.
General Specifications
LCD w/backlight	3½ digits, 6000 counts, updates 4/sec
Battery type	2 AA, NEDA 15 A, IEC LR6
Battery life	400 Hours
Memory	Record up to 65000 readings
RF communications	2.4 GHZ ISM Band
RF communication range	Open air, unobstructed	Up to 20 m
	Obstructed, sheetrock wall	Up to 6.5 m
	Obstructed, concrete wall or steel electrical enclosure	Up to 3.5 m
Operating temperature	-10°C to +50°C
Storage temperature	-40°C to +60°C
Temperature coefficient	0.1 X (specified accuracy)/°C ( 28°C)
Operating humidity	90% at 35°C, 45% at 40°C, 45% at 50°C
Altitude	Operating	2,000 m
	Storage	12,000 m
EMC	EN 61326–1:2006
Safety compliance	ANSI/ISA 61010–1 / (82.02.01)	3rd edition
	CAN / CSA–C22.2 No 61010–1–12	3rd edition
	UL 61010–1	3rd edition
	IEC/EN 61010–1	2010
Safety rating	CAT IV 600 V, CAT III 1000 V
Certifications	CSA, CE, FCC: T68-FBLE IC: 6627A-FBLE
Ingress Protection (IP) rating	IP42
Pollution Degree	2
Size (HxWxD)	16.5 x 6.35 x 1.4 cm (6.5 x 2.5 x 1.4 in)
Weight	.22 kg (8 oz)
Warranty	Three years
Note: Not compatible with Fluke CNX test tools

Datasheet

Fluke v3000 FC Wireless AC Voltage Module | Data sheetsPDF

User Manual

Official user manualPDF
