Testo 755-2 current/voltage tester

testo 755-2 current/voltage tester key features:

All-in-one voltage tester and current measuring instrument: the innovative testo 755-2. A multitasker for almost all daily electrical measuring tasks. With automatic measurement parameter detection, exchangeable measuring tips and an extended voltage range up to 1,000 V.

(1 customer review)
SKU: 742

AED 660 (excl.VAT)

We are not Supporting COD Payments Terms Outside UAE

17 People watching this product now!

Testo 755-2 current/voltage tester

Order-Nr.  0590 7552

With the testo 755-2, you are equipped for the most important tasks of the working day. The current/voltage tester is suitable for determining voltage or de-energization, checks voltage level and continuity, and measures the flow of current along with current consumption. It is a simple task to change faulty measuring tips – without needing to replace the instrument. And the automatic measurement parameter detection and integrated torch make operation and measurement particularly easy and reliable.

Compared to the testo 755-1, the testo 755-2 has an increased voltage range of up to 1,000 V and enables rotating magnetic field measurement along with single pole voltage testing to determine quickly whether conductors are live. Purchase testo  755-1 now and compare it with other products through mme.

testo 755-2 current/voltage tester specification

  • Operating humidity : 0 to 75 %RH
  • Storage temperature: -15 to +60 °C
  • Weight: 320 g
  • Dimensions : 199 x 62 x 40 mm
  • Operating temperature: -10 to +50 °C
  • Protection class: IP64
  • Standards: EN 61243-3; EN 61010-1
  • Battery type: 2 AAA micro batteries
  • Overvoltage Category : CAT IV 600V; CAT III 1000V
  • Measuring range Resistance: 30 to 100 kOhm
  • Resolution Resistance: max. 1 Ohm
  • Accuracy Resistance : ± (1.0 % of mv + 5 Digit)
  • Measuring range AC current: 0.1 to 200 A
  • Resolution AC current: max. 0.1 A
  • Accuracy AC current : ± (3 % of mv + 3 Digit)
  • Measuring range AC voltage: 6 to 1000 V
  • Resolution AC voltage: max. 0.1 V
  • Accuracy AC voltage : ± (1.5 % of mv + 3 Digit)
  • Measuring range DC voltage: 6 to 1000 V
  • Resolution DC voltage: max. 0.1 V
  • Accuracy DC voltage: ± (1.5 % of mv + 3 Digit)
Related Product

The Fluke T6-1000 Pro is a closely related product to the Testo 755-2, offering similar functionality and durability for electrical testing. It features non-contact voltage measurement, simultaneous voltage and current measurement, and a rugged design. The T6-1000 Pro is a reliable and efficient option for professionals seeking accurate measurements in the field.

Other related products of this device that we can name are testo 750-1,750-3, T6-1000.
