Hioki CM4372 AC/DC Clamp Meter

Hioki CM4372 AC/DC Clamp Meter

Hioki clamp-on meters are top-of-the-line measuring instruments that draw on Hioki’s experience with modern sensing technology. The Hioki CM4372 is a 600A True RMS clamp meter with stronger jaws, a wider -25°C to 65°C operating temperature range, and an IP54 dustproof and waterproof enclosure that enables professionals to work quickly in challenging situations like the creation, upkeep, and repair of machinery and devices like electric vehicles.

The clamp maintenance checks of electrical and solar power equipment are made possible by the high-voltage DC measurement capability of up to 1700 V. Using Bluetooth® wireless technology, measured values can be transmitted to a smartphone or tablet and shown as waveforms in real time.

Hioki CM4372 Specifications

• DC Current: 20.00 A/600.0 A / accuracy: ±1.3% rdg
• AC Current: 20.00 A/600.0 A/accuracy 45-66 Hz: ±1.3% rdg
• DC+AC Current: 20.00 A/600.0 A/accuracy DC, 45-66 Hz: ±1.3% rdg
• DC Voltage: 600.0 mV to 1700 V / accuracy: ±0.5% rdg
• AC Voltage: 6.000 V to 1000 V / accuracy 45 – 66 Hz: ±0.9% rdg
• DC+AC Voltage: 6.000 V to 1000 V / accuracy DC, 45 – 66 Hz: ±1.0% rdg
• Resistance: 600.0 Ω to 600.0 kΩ / accuracy: ±0.7% rdg
• Electrostatic  Capacitance: 1.000 μF to 1000 μF / accuracy: ±1.9% rdg
• Frequency: 9.999 Hz to 999.9 Hz / accuracy: ±0.1% rdg
• Temperature (K): -40.0 to 400.0 ˚C
• Dimensions and mass: 65 mm (2.56 in) W × 215 mm (8.46 in) H × 35 mm (1.38 in) D mm, 340 g

Related Products

The Hioki CM4373 builds upon the foundation of its predecessor, the CM4372, to offer an advanced electrical current clamp meter with enhanced capabilities.
