Description

At Mohammad Mahdi Electronics, we offer the Hioki MEMORY HiCORDER MR8847-52, a high-performance memory recorder designed for capturing and analyzing complex electrical signals. With its advanced features and robust construction, this memory recorder is ideal for a wide range of applications, from electrical safety testing to research and development.

Whether you’re working in a laboratory, testing electrical equipment, or conducting research, the Hioki MEMORY HiCORDER MR8847-52 is the perfect tool for capturing and analyzing complex electrical signals. With its high-speed recording capabilities and advanced measurement functions, you can trust that you’re getting accurate and reliable results.

Hioki MR8847-52 Key Features

The Hioki MEMORY HiCORDER MR8847-52 features a range of advanced measurement functions, including MEMORY (high-speed recording), RECORDER (real-time recording), and X-Y RECORDER (X-Y real-time recording). It also features a range of other functions, including waveform judgment (at Memory, FFT function) and removable storage via USB memory, CF card slot, or hard disk drive.

16 analog channels + 16 logic channels (standard)
10 analog channels + 64 logic channels (standard)
5 mV to 20 V/div, 12 ranges, resolution : 1/100 of range
DC to 5 MHz (-3dB), using the 8966
5 µs to 5 min/div, 26 ranges,at 100 points/div resolution
MEMORY (high-speed recording), RECORDER (real-time recording)
Waveform judgment (at Memory, FFT function)
10.4 inch TFT color LCD (SVGA, 800 × 600 dots)

Who Needs the Hioki MR8847-52?

The Hioki MEMORY HiCORDER MR8847-52 is designed for a wide range of applications, including electrical safety testing, research and development, and laboratory testing. Whether you’re working in a laboratory, testing electrical equipment, or conducting research, this memory recorder is the perfect tool for capturing and analyzing complex electrical signals.

With its advanced features and robust construction, the Hioki MEMORY HiCORDER MR8847-52 is ideal for a wide range of industries, including electrical engineering, electronics, and research and development.

At MME, we understand the importance of accurate and reliable measurement data. That’s why we offer the Hioki MEMORY HiCORDER MR8847-52, a high-performance memory recorder designed to meet the needs of even the most demanding applications.

Hioki MR8847-52 Applications

The Hioki MEMORY HiCORDER MR8847-52 is designed for a wide range of applications, including:

Electrical safety testing
Research and development
Laboratory testing
Electrical engineering
Electronics

Why Buy Hioki MR8847-52 from Mohammad Mahdi Electronics?

Browse our recorders and dataloggers. Read more in our measurement guides.

At Mohammad Mahdi Electronics, we offer the Hioki MEMORY HiCORDER MR8847-52 at a competitive price, with fast shipping and excellent customer service. We also offer a range of accessories and support services to ensure that you get the most out of your memory recorder.

Whether you’re working in a laboratory, testing electrical equipment, or conducting research, the Hioki MEMORY HiCORDER MR8847-52 is the perfect tool for capturing and analyzing complex electrical signals. With its advanced features and robust construction, you can trust that you’re getting accurate and reliable results.

Hioki MR8847-52 Specifications

Number of channels	[8 analog input modules]: 16 analog channels + 16 logic channels (standard) [5 analog input modules + 3 logic input modules]: 10 analog channels + 64 logic channels (standard 16 channels + 48 channels in logic input modules) * For analog modules, channels are insulated vs. each other and vs. unit ground. For logic modules and integrated standard logic channels, all channels use the unit ground.
Measurement ranges (20 div full-scale)	5 mV to 20 V/div, 12 ranges, resolution : 1/100 of range (using the 8966) 5 mV to 20 V/div, 12 ranges, resolution : 1/1600 of range (using the 8968)
Max. allowable input	400 V DC (using the 8966/8968)
Frequency characteristics	DC to 5 MHz (-3dB, using the 8966), DC to 100 kHz (-3dB, using the 8968)
Time axis (MEMORY)	5 µs to 5 min/div, 26 ranges,at 100 points/div resolution, three steps of time-axis magnification from ×2 to ×10, and 13 steps of time-axis compression from ×1/2 to ×1/20,000
Measurement functions	MEMORY (high-speed recording), RECORDER (real-time recording), X-Y RECORDER (X-Y real-time recording), FFT
Other functions	Waveform judgment (at Memory, FFT function)
Memory capacity	MR8847-01: 32M-words/ch (using 2 Analog channels) to 4M-words/ch (using 16 Analog channels), Total capacity 64MW memory MR8847-02: 128M-words/ch (using 2 Analog channels) to 16M-words/ch (using 16 Analog channels), Total capacity 256MW memory MR8847-03: 256M-words/ch (using 2 Analog channels) to 32M-words/ch (using 16 Analog channels), Total capacity 512MW memory
Removable storage	USB memory, CF card slot × 1 (Up to 2 GB), Hard disk drive (option, 80GB)
Printing	216 mm (8.50 in) × 30 m (98.43 ft), thermal paper roll, Recording speed : Max. 50 mm (1.97 in)/sec
Display	10.4 inch TFT color LCD (SVGA, 800 × 600 dots)
Displayable languages	English, Japanese, Korean, and Chinese
External interfaces	[LAN]:100BASE-TX; Functions: DHCP, DNS supported, FTP server, HTTP server [USB]: USB2.0 compliant, series A receptacle 1 port, series B receptacle 1 port (file transfer to PC, remort control from PC)
Power supply	100 to 240 V AC, 50/60 Hz (130 VA max., when using printer: 220 VA max.) 10 to 28 V DC (when using the optional factory-installed DC power unit 9784)
Dimensions and mass	351 mm (13.82 in) W × 261 mm (10.28 in) H × 140 mm (5.51 in) D, 7.8 kg (275.1 oz) (main unit only)
Included accessories	Instruction Manual ×1, Measurement Guide ×1, Application Disk (Wave Viewer Wv, Communication Commands table) ×1, Power cord ×1, Input cord label ×1, USB cable ×1, Printer paper ×1, Roll paper attachment ×2
