Description

The MEMORY HiCORDER MR8847-53 from Hioki is a high-performance memory recorder designed for capturing and analyzing complex electrical signals. With its advanced features and robust construction, this device is ideal for a wide range of applications, including electrical safety testing, power quality analysis, and more.

Whether you’re working in a laboratory, testing facility, or field environment, the MEMORY HiCORDER MR8847-53 provides the flexibility and accuracy you need to get the job done. With its high-speed recording capabilities, advanced measurement functions, and user-friendly interface, this device is a valuable tool for anyone working with electrical signals.

Hioki MR8847-53 Key Features

The MEMORY HiCORDER MR8847-53 offers a range of advanced features, including:

16 analog channels + 16 logic channels (standard)
10 analog channels + 64 logic channels (standard)
5 mV to 20 V/div, 12 ranges, resolution : 1/100 of range
DC to 5 MHz (-3dB, using the 8966)
5 µs to 5 min/div, 26 ranges
32M-words/ch to 4M-words/ch, Total capacity 64MW memory
10.4 inch TFT color LCD (SVGA, 800 × 600 dots)
100 to 240 V AC, 50/60 Hz (130 VA max.)

Who Needs the Hioki MR8847-53?

The MEMORY HiCORDER MR8847-53 is designed for a wide range of applications, including:

Electrical safety testing and certification

Power quality analysis and monitoring

Electrical measurement and testing

Research and development

Field testing and measurement

Hioki MR8847-53 Applications

The MEMORY HiCORDER MR8847-53 is suitable for a variety of applications, including:

Electrical safety testing
Power quality analysis
Electrical measurement and testing
Research and development
Field testing and measurement

Why Buy Hioki MR8847-53 from mme-ae?

At mme-ae, we offer the MEMORY HiCORDER MR8847-53 from Hioki at a competitive price, along with expert advice and support. Whether you’re looking for a high-performance memory recorder for your laboratory or field testing needs, we have the solution for you.

For more information on the MEMORY HiCORDER MR8847-53, please visit our electrical safety testing guide or contact us today to speak with one of our experts.

Hioki MR8847-53 Specifications

Number of channels	[8 analog input modules]: 16 analog channels + 16 logic channels (standard) [5 analog input modules + 3 logic input modules]: 10 analog channels + 64 logic channels (standard 16 channels + 48 channels in logic input modules) * For analog modules, channels are insulated vs. each other and vs. unit ground. For logic modules and integrated standard logic channels, all channels use the unit ground.
Measurement ranges (20 div full-scale)	5 mV to 20 V/div, 12 ranges, resolution : 1/100 of range (using the 8966) 5 mV to 20 V/div, 12 ranges, resolution : 1/1600 of range (using the 8968)
Max. allowable input	400 V DC (using the 8966/8968)
Frequency characteristics	DC to 5 MHz (-3dB, using the 8966), DC to 100 kHz (-3dB, using the 8968)
Time axis (MEMORY)	5 µs to 5 min/div, 26 ranges,at 100 points/div resolution, three steps of time-axis magnification from ×2 to ×10, and 13 steps of time-axis compression from ×1/2 to ×1/20,000
Measurement functions	MEMORY (high-speed recording), RECORDER (real-time recording), X-Y RECORDER (X-Y real-time recording), FFT
Other functions	Waveform judgment (at Memory, FFT function)
Memory capacity	MR8847-01: 32M-words/ch (using 2 Analog channels) to 4M-words/ch (using 16 Analog channels), Total capacity 64MW memory MR8847-02: 128M-words/ch (using 2 Analog channels) to 16M-words/ch (using 16 Analog channels), Total capacity 256MW memory MR8847-03: 256M-words/ch (using 2 Analog channels) to 32M-words/ch (using 16 Analog channels), Total capacity 512MW memory
Removable storage	USB memory, CF card slot × 1 (Up to 2 GB), Hard disk drive (option, 80GB)
Printing	216 mm (8.50 in) × 30 m (98.43 ft), thermal paper roll, Recording speed : Max. 50 mm (1.97 in)/sec
Display	10.4 inch TFT color LCD (SVGA, 800 × 600 dots)
Displayable languages	English, Japanese, Korean, and Chinese
External interfaces	[LAN]:100BASE-TX; Functions: DHCP, DNS supported, FTP server, HTTP server [USB]: USB2.0 compliant, series A receptacle 1 port, series B receptacle 1 port (file transfer to PC, remort control from PC)
Power supply	100 to 240 V AC, 50/60 Hz (130 VA max., when using printer: 220 VA max.) 10 to 28 V DC (when using the optional factory-installed DC power unit 9784)
Dimensions and mass	351 mm (13.82 in) W × 261 mm (10.28 in) H × 140 mm (5.51 in) D, 7.8 kg (275.1 oz) (main unit only)
Included accessories	Instruction Manual ×1, Measurement Guide ×1, Application Disk (Wave Viewer Wv, Communication Commands table) ×1, Power cord ×1, Input cord label ×1, USB cable ×1, Printer paper ×1, Roll paper attachment ×2
