Hioki RM3548 Resistance Meter
Hioki RESISTANCE METER rm 3548
• 0.02 % basic accuracy, 0.1 μΩ max. resolution, 1 A max. testing current, 1A max. testing current
• Measure from 0.0 µΩ (testing current 1 A) to 3.5 MΩ • Easily record up to 1,000 data points in memory simply by applying the instrument’s probes
• Smoothly capture temperature-rise test data using interval measurement
• Portable design is ideal for the maintenance and testing of large equipment
AED 3,989 (excl.VAT)
We are not Supporting COD Payments Terms Outside UAE
Hioki RM3548 Resistance Meter
The Hioki RM3548 HiTester is a standout device in the field of resistance measurement, delivering exceptional accuracy and versatility for a range of industrial applications. Designed to cater specifically to the needs of professionals engaged in the maintenance and production of large-scale equipment, the RM3548 excels in scenarios where precision is paramount.
The Hioki RM3548 is primarily used in settings such as power plants, automotive manufacturing, and other sectors where large machinery plays a critical role. Its precision in measuring winding and weld resistances makes it an indispensable tool for ensuring the optimal performance of electrical and mechanical systems.
Key Features of the Hioki RM3548 HiTester:
- High Precision Measurement: The RM3548 boasts a basic accuracy of 0.02% and a maximum resolution of 0.1 μΩ, enabling it to provide highly accurate measurements crucial for the thorough assessment of large motors, stators, and other substantial components. This feature is particularly beneficial in the automotive industry, where the device is used for testing and maintaining hybrid and electric vehicle components.
- Wide Measurement Range: With the ability to measure resistance from as low as 0.0 μΩ (with a 1 A testing current) up to 3.5 MΩ, the HiTester is equipped to handle a broad spectrum of testing requirements. This range ensures that it can be applied across various stages of production and maintenance, from intricate electronics to heavy industrial machinery.
- Data Recording Capability: The RM3548 simplifies the process of data collection by allowing up to 1,000 data points to be recorded in memory effortlessly, merely by applying the instrument’s probes. This feature enhances efficiency and accuracy in data logging, crucial during extensive testing sessions.
- Temperature-Rise Test Data Capture: Engineers can smoothly capture temperature-rise test data using interval measurement settings, which is essential for evaluating equipment performance under different operating temperatures. This capability ensures that all components operate safely and effectively under their expected range of conditions.
- Portable and Durable Design: The portable nature of the RM3548 HiTester makes it an excellent tool for on-site measurements in various settings. Its design is not only practical for easy transport but also robust enough to withstand the rigors of fieldwork, making it a reliable choice for technicians who require a dependable tool in diverse environments.
more information
MME-AE is a renowned importer and distributor of micro ohmmeter in UAE and various other countries, providing the most competitive prices in the market. for microohmmeter price and obtaining detailed information, we encourage you to get in touch with our knowledgeable experts at MME-AE.
Hioki RESISTANCE METER RM3548 specifications:
- Resistance range 3 mΩ (3.5000 mΩ display Max., 0.1 µΩ resolution) to 3 MΩ range (3.5000 MΩ display Max., 100 Ω resolution), 10 steps
Measurement accuracy: ±0.020 % rdg. ±0.007 % f.s. - Testing current [at 3 mΩ range] 1 A DC to [at 3 MΩ range] 500 nA DC
- Open-terminal voltage 5.5 V DC max.
- Temperature measurement -10.0 to 99.9°C, accuracy: ±0.50°C (Temperature Sensor Z2002 and RM3548 combined accuracy)
- Measurement speed Fixed
- Display refresh rate Without OVC: approx. 100ms, With OVC: approx. 230ms
3 reviews for Hioki RM3548 Resistance Meter
Clear filtersYou must be logged in to post a review.
Brand
Hioki
Hioki is a renowned Japanese brand known for its expertise in developing and manufacturing electrical measuring instruments. The company, Hioki E.E. Corporation, was established in 1935, and since then, it has committed itself to providing innovative solutions in the field of electrical measurement.
Hioki's product range is extensive, including devices such as digital multimeters, clamp meters, power meters, and oscilloscopes. These instruments are vital for various applications in research and development, maintenance, and production testing across industries like electronics, energy, and automotive. One of the key strengths of Hioki is its focus on precision and reliability, traits that are crucial in measurement instruments. Hioki’s products are designed to offer accuracy and durability, which make them preferred choices among professionals worldwide.
Moreover, Hioki emphasizes technological innovation and quality. The company invests significantly in research and development to keep up with evolving technological trends and to ensure their products meet the highest standards. This commitment to quality is reflected in their adherence to international certifications and standards. Hioki also values environmental sustainability, integrating eco-friendly practices in their operations and product designs. This includes efforts to reduce the environmental impact of their manufacturing processes and to design products that are energy efficient.
specifications
Specification Category | Details |
---|---|
Resistance Range | 3 mΩ (3.5000 mΩ display Max., 0.1 µΩ resolution) to 3 MΩ range (3.5000 MΩ display Max., 100 Ω resolution), 10 steps |
Measurement Accuracy | ±0.020 % rdg. ±0.007 % f.s. |
Testing Current | [at 3 mΩ range] 1 A DC to [at 3 MΩ range] 500 nA DC |
Open-Terminal Voltage | 5.5 V DC max. |
Temperature Measurement | -10.0 to 99.9°C, accuracy: ±0.50°C (Temperature Sensor Z2002 and RM3548 combined accuracy) |
Measurement Speed | Fixed |
Display Refresh Rate | Without OVC: approx. 100ms, With OVC: approx. 230ms |
Functions | Temperature correction, temperature conversion, offset voltage compensation (OVC), comparator (ABS/REF%), length conversion, judgment sound setting, auto hold, auto power save (APS), averaging, panel store/panel load, USB communication interface (RM3548 internal memory is recognized as a mass storage device when connected to a PC) |
Memory Storage | Number of recordable data points: (manual/auto) Up to 1,000, (interval) Up to 6,000; Interval: 0.2 to 10.0s (0.2s steps); Acquisition of data from memory: display, USB mass storage (CSV, TXT files) |
Power Supply | LR6 (AA) Alkaline batteries ×8, Continuous use: 10 hours (Under our company’s conditions), Rated power consumption: 5 VA max. |
Dimensions and Mass | 192 mm (7.56 in) W × 121 mm (4.76 in) H × 55 mm (2.17 in) D, 770 g (27.2 oz) |
