PCE-CT 65 Coating Thickness Gauge

The PCE-CT 65 is a coating thickness gauge that uses magnetic (ferrous) or eddy current (non-ferrous) induction to perform non-destructive measurements of coating thickness and dry film (DFT) on substrates.

SKU:58143

MME Shopping Event

Hurry and get discounts on Most of MME Products up to 20%

AED 872 (excl.VAT)

14People watching this product now!

PCE-CT 65 Coating Thickness Gauge

The PCE-CT 65 is a coating thickness gauge that uses magnetic (ferrous) or eddy current (non-ferrous) induction to perform non-destructive measurements of coating thickness and dry film (DFT) on substrates. metals such as steel and aluminum. This sensor gauge is ideal for surface coating and powder coating inspection, automotive paint inspection, coating material inspection, and manufacturing quality control applications.

The easy-to-use downloadable PC-compatible software included with this thickness gauge enables detailed analysis of measurement results via a computer. The measured values ​​are displayed in a table and different working modes can be selected for data filtering.

The statistics include each workgroup’s maximum, minimum, and average values. Statistics can be divided into ferrous and non-ferrous materials. The software also counts the number of reads recorded in each material group. For more details, please refer to the user manual.

coating thickness gauge pce-ct 65 Features

  • Includes calibration shims and blocks for DIY accuracy testing, a carrying case for easy transport, and a 2-year warranty against manufacturer defects
  • Optional ISO calibration certificate available for purchase separately – see accessories tab for details
  • Features two measuring modes (ferrous and non-ferrous) with integrated sensors for comfortable, one-handed operation
  • Saves up to 1500 measurements to memory
  • It comes with a USB cable and downloadable PC software (see downloads tab) for detailed analysis of measurement results via computer

more information of pce-ct 65

MME-AE is a renowned importer and distributor of coating thickness gauges in Dubai and various other countries, providing the most competitive prices in the market. For purchasing coating thickness gauge and obtaining detailed pricing information, we encourage you to get in touch with our knowledgeable experts at MME-AE. to buy pce ct 65 or want to know about pce ct 65 price visit our website.

PCE-CT 65 Specifications:

  • Measuring range: 0 … 1350 µm / 0 … 53.1 mils
  • Accuracy: 0 … 1000 µm: (±2.5 % ±2 µm) 1000 µm … 1350 µm: ±3.5 % 0 … 39.3 mils: (±2 % ±0.08 mils)
    39.3 mils … 53.1 mils: ±3.5 %
  • Resolution: 0 … 100 µm: 0.1 µm 100 µm … 1000 µm: 1 µm in 1000 mm … 1350 µm: 0.01 mm 0 … 10 mils: 0.01 mils 10 mils … 53.1 mils: 0 … 1 mils
  • Smallest surface: Ø 7 mm / Ø 0.3 in
  • Min. curvature radius: 1.5 mm / 0.05 in
  • Min. substrate thickness: 0.5 mm / 0.02 in
  • Non-ferrous metals
  • Principle: Eddy current
  • Measuring range: 0 … 1350 µm / 0 … 53.1 mils
  • Accuracy: 0 … 1000 µm: ±(2.5 % ±2 µm) 1000 µm … 1350 µm: ±3.5 % 0 … 39.3 mils: ±(2 % ±0.08 mils) 39.3 mils … 53.1 mils: ±3.5 %
  • Resolution: 0 … 100 µm: 0.1 .mu.m 100 µm … 1000 µm: 1 µm in 1000 mm … 1350 µm: 0.01 mm 0 … 10 mils: 0.01 mils 10 mils … 53.1 mils: 0 … 1 mils
  • Smallest surface: Ø 5 mm / Ø 0.2 in
  • Min. curvature radius: 3 mm / 0.1 in
  • Min. substrate thickness: 0.3 mm / 0.01 in
  • Units: µm, mils
  • Functions: Alarm function, display lighting, automatic shutdown, calibration, memory function
  • Memory option: 30 storage groups with a capacity of 50 measurements each = 1500 measurements total
  • Interface: USB
  • Environmental conditions: 0 … 40°C / 32° F … 104°F, 20% … 90% rh
  • Power supply: 2 x 1.5V AAA batteries
