TESTO 324 Pressure and leakage measuring instrument basic set
Short Description:
TESTO 324 Pressure and leakage measuring instrument basic set key features :
- Included in the set: DVGW-tested testo 324 pressure and leakage measuring instrument, including integrated pressure pump, mains unit, system case with feeding unit, connection block and connection hose, manual test pump, adapter for gas boiler test port and ¾” and 1¼” high-pressure stage stops
- Automatic pressure build-up to 300 mbar by means of an integrated pressure pump; manual test pump for generating higher pressures, e.g. for the 1 bar test
- All the important measurements in one instrument: tightness test, load test and serviceability test
- Step-by-step guide through regulatory-compliant measurement menus: conducting tests on gas pipes has never been easier
Product purchase
AED 7,744 (excl.VAT)
20
People watching this product now!
Terms of sending goods ›
TESTO 324 Pressure and leakage measuring
Order-Nr. 0563 3240 70
Over the course of time gas pipes can become leaky. The Testo 324 basic set enables you to get down to work straight away and carry out all relevant and legally prescribed tests on gas pipes.
TESTO 324 Pressure and leakage measuring instrument basic set specifications:
Temperature – NTC :
- Measuring range: -20 to +100 °C
Temperature – TC Type K (NiCr-Ni) :
- Measuring range: -40 to +600 °C
- Accuracy : ±0.5 °C or ±0.5 %
Absolute Pressure :
- Measuring range: 600 to 1150 hPa
- Accuracy: ±3 hPa
- Overload: to 1200 hPa
Leakage measurement :
- Measuring range : 0 to 10 l/h
- Accuracy: ±0.2 l/h or ±5 % of mv
- Resolution: 10.0
| Leakage measurement |
Measuring range: 0 to 10 l/h |
|---|---|
| Temperature range/resolution/aacuracy |
Type 5K Measuring range: -20 to +100 °C ,Type K Accuracy: ±0.5 °C or ±0.5% ,Type K Measuring range: -40 to +600 °C |
| Weight |
7.0 kg |
| IP rating |
IP40 |
| Power |
1 x rechargeable battery |
| Operating temperature |
+5 to +40 °C |
| Storage temperature |
-20 to +50 °C |
| Measurement Unit |
l/h, bar, hPa |
| Pressure measurement |
Measuring range: 0 to 1000 hPa |
Data Sheet
