Testo 400 air flow kit with 16 mm vane probe

(1 customer review)

Short Description:

TESTO 400 air flow kit with 16 mm vane probe key features:

  • Standard-compliant determination of the volume flow in ducts using grid measurements as per EN ISO 12599 and ASHRAE 111
  • Determination of the volume flow at outlets by measuring the reference pressure and entering the manufacturer-specific K-factor
  • Smart, intuitive measurement programs, complete your measurement with full documentation on site at the customer’s premises or carry out further analysis using the testo DataControl measurement data management and analysis software
  • In the kit: testo 400 universal IAQ instrument, 16 mm vane probe (with Bluetooth® handle and telescope), vane probe head (Ø 100 mm), high-precision humidity/temperature probe head, 90° angle, case
Product purchase
SKU: 2175 Category:
Brand:Testo

AED 12,675 (excl.VAT)

14 People watching this product now!
Terms of sending goods ›
  •  In-stock items are delivered within 2 business days.
  • We are not Supporting COD Payments Terms Outside UAE

Testo 400 Air flow Kit With 16 mm Vane Probe

Order-Nr.  0563 0400 72

Ideal kit for IAQ professionals, with a focus on airflow measurement. You will receive the testo 400 universal IAQ measuring instrument with intuitive measurement menus, one vane probe head (Ø 16 mm), one vane probe head (Ø 100 mm), and one high-precision humidity/temperature probe head – all three can be attached to the Bluetooth® handle supplied. For measurements at ceiling outlets, simply combine the 100 mm vane probe with the telescope (which can be extended up to 1.0 m) and the 90° angle.

Testo 400 Air Flow Kit With 16 mm Vane Probe Specifications:

  • testo 400 universal IAQ instrument, silicone hoses, mains unit with USB cable, calibration protocol, instruction manual (0560 0400)
  • Vane probe with Bluetooth® including temperature sensor (consisting of 16 mm vane probe head, handle adapter, and Bluetooth® handle), 4 x AA batteries, telescope (can be extended up to 1.0 m), and calibration protocol (0635 9571)
  • Vane probe head (Ø 100 mm) including temperature sensor, bracket for testament measurement funnel, and calibration protocol (0635 9430)
  • High-precision humidity/temperature probe head including calibration protocol (0636 9770)
    Please do not use the probe head in condensing atmospheres. For continuous application in high-humidity ranges
    > 80% RH at ≤ 30 °C for > 12 h
    > 60% RH at > 30 °C for > 12 h
    Please get in touch with Testo Service or contact us via the Testo website
  • 90° angle for connecting vane probes (Ø 100 mm) (0554 0991)
  • Transport case for airflow measurements (0516 1400)
Humidity

16 mm vane probe with Bluetooth:
0 to 100 %RH, ±(0.6 %RH + 0.7% of m.v.) (0 to 90 %RH), 0.01 %RH
0 to 100 %RH, ±(1.0 %RH + 0.7% of m.v.) (90 to 100 %RH), 0.01 %RH

Dimensions

16 mm vane probe with Bluetooth: 790 x 50 x 40 mm

,

High-precision humidity/temperature probe head: 160 x 28 x 28 mm

,

testo 400: 210 x 95 x 39 mm

,

Vane probe head (Ø 100 mm): 180 x 105 x 46 mm

Weight

16 mm vane probe with Bluetooth: 400 g

,

High-precision humidity/temperature probe head: 20 g

,

testo 400: 510 g

,

Vane probe head (Ø 100 mm): 125 g

Operating temperature

16 mm vane probe with Bluetooth: -10 to +70 °C

,

High-precision humidity/ temperature probe head: -20 to +70 °C

,

testo 400: -5 to +45 °C

,

Vane probe head (Ø 100 mm): -20 to +70 °C

Storage temperature

16 mm vane probe with Bluetooth: -10 to +70 °C

,

High-precision humidity/ temperature probe head: -20 to +70 °C

,

testo 400: -20 to +60 °C

,

Vane probe head (Ø 100 mm): -20 to +70 °C

Air velocity range/resolution/accuracy

High-precision humidity/ temperature probe head: 0.3 to 35 m/s, ±(0.1 m/s + 1.5% of m.v.) (0.3 to 20 m/s), 0.1 m/s

,

High-precision humidity/ temperature probe head: 0.3 to 35 m/s, ±(0.2 m/s + 1.5% of m.v.) (20.01 to 35 m/s), 0.1 m/s

,

Vane probe head (Ø 100 mm): 0.6 to 50 m/s, , ±(0.2 m/s + 2% of m.v.) (40.1 to 50 m/s), 0.1 m/s

,

Vane probe head (Ø 100 mm): 0.6 to 50 m/s, ±(0.2 m/s + 1% of m.v.) (0.6 to 40 m/s), 0.1 m/s

Temperature/range/resolution/accuracy

High-precision humidity/temperature probe head: -20 to +70 °C, ±0.3 °C (15 to 30 °C) and ±0.5 °C (remaining meas. range), 0.1 °C

,

Vane probe (Ø 16 mm) with Bluetooth, -10 to +70 °C, ±1.8 °C, 0.1 °C

,

Vane probe head (Ø 100 mm): -20 to +70 °C, ±0.5 °C, 0.1 °C

Pressure

testo 400 universal IAQ instrument
Differential pressure: -100 to +200 hPa, (±0.3 Pa + 1% of m.v. (0 to +25 hPa) or ±0.1 hPa + 1.5% of m.v. (+25.001 to +200 hPa)), 0.001 hPa
Absolute pressure
700 to 1100 hPa, ±3 hPa, 0.1 hPa
