EXTECH TK430-IR Electrical Test Kit
2 Comments
EXTECH TK430-IR Electrical Test Kit key features
- True RMS DMM with 11 functions and 0.3% basic accuracy
- AC/DC Voltage & Current, Resistance, Capacitance, Frequency, Temperature, Diode/Continuity, Duty Cycle
- Input fuse protection and misconnection warning
- 20A max Current
- Type K temperature measurements
- Data hold, Relative, Auto power off
- Large-digit backlit LCD
Terms of sending goods ›
This product is discontinued.
Order Via phone number
Order Via Online Form
Estimated Delivery: 2–4 business weeks
Description
EXTECH TK430-IR Electrical Test Kit
True RMS MultiMeter, Clamp meter, and IR Thermometer kit. Ideal for electrical testing needs including installation and repair of electrical systems, HVAC equipment, and large appliances. Includes the EX430: True RMS, Auto Ranging Multimeter with 11 functions. MA200: 400 Amp Clamp meter with basic AC Current and 1mA resolution. 42510: InfraRed Thermometer (-58 to 1000 degrees Fahrenheit /-50 to 538 degree Celsius) with the laser pointer. 40130: Non-contact Voltage detector (from 100 Volt to 600 Volt AC).
EXTECH TK430-IR Electrical Test Kit Specifications
- V DC or V AC 600V DC/AC 200Vrms on 400mV range
- mA AC/DC 500mA 250V fast acting fuse
- A AC/DC 20A 250V fast acting fuse(30 seconds max every 15 minutes)
- Temperature 60V DC/24V AC
- Diode Test Test current of 0.3mA maximum open circuit voltage 1.5V DC typical
- Continuity Check Audible signal will sound if the resistance is less than 150Ω (approx.) test current <0.7mA
- Temperature Sensor Requires type K thermocouple
- Input Impedance >7.5M Ω (VDC & VAC)
- AC Response True rms
- ACV Bandwidth 50Hz to 1kHz
- Display 4000 count backlit liquid crystal
- Overrange indication ”OL” is displayed
Related Product
Additional information
| max__temperature__range (thermometer) |
up to 550 °C |
|---|---|
| thermometer__type (thermometer) |
infrared thermometer |
specifications
specifications
| Specification | Value |
|---|---|
| V DC or V AC | 600V DC/AC 200Vrms on 400mV range |
| mA AC/DC | 500mA 250V fast acting fuse |
| A AC/DC | 20A 250V fast acting fuse (30 seconds max every 15 minutes) |
| Temperature | 60V DC/24V AC |
| Diode Test | Test current of 0.3mA maximum open circuit voltage 1.5V DC typical |
| Continuity Check | Audible signal will sound if the resistance is less than 150Ω (approx.) test current <0.7mA |
| Temperature Sensor | Requires type K thermocouple |
| Input Impedance | >7.5M Ω (VDC & VAC) |
| AC Response | True rms |
| ACV Bandwidth | 50Hz to 1kHz |
| Display | 4000 count backlit liquid crystal |
| Overrange indication | ”OL” is displayed |
