Fluke 55XXA/LEADS Thermocouple & Test Lead Set

Description

Fluke 55XXA/LEADS Thermocouple and Test Lead Set Overview

The Fluke 55XXA/LEADS (P/N 5128204) is Fluke Calibration’s thermocouple and test lead set with case for multi-product calibrators. Fluke lists it for the Fluke 5560A multi-product calibrator, and the 5560A / 5550A / 5540A manual lists the set as standard equipment.

The set brings together the stackable, shielded and high-current test leads, J, K and Cu thermocouple extensions, thermocouple assemblies and adapters in one case. Calibration labs and service teams use it to keep a complete, matched lead set with each calibrator, or to replace worn leads.

Key Features

Complete set for voltage, current and thermocouple calibration work
Shielded calibration leads rated 1000 V max (calibration use)
Stackable and high-current leads rated 30 A max
Colour-coded J, K and Cu thermocouple extensions (3 ft)
K-type beaded and J thermocouple assemblies, Cu-Cu shorting plug and K to 4 mm banana adapter
Carrying case keeps the set together

Fluke 55XXA/LEADS Contents and Specifications

Fluke 55XXA/LEADS contents and ratings
Fluke part number	5128204
EAN	0 095969 919227
Compatible calibrators	Fluke 5560A (per Fluke); supplied as standard equipment with the 5560A / 5550A / 5540A (per the calibrator manual)
Stackable test leads	Red/black; 30 V AC / 60 V DC max (non-contact use), 30 A max
Shielded calibration test leads	1000 V max (calibration use only), 1500 V pk max transient, non-contact use, 3.2 A max
High-current test leads	30 V AC / 60 V DC, 30 A max
Thermocouple extension wires, 3 ft	Type J (brown wire, black connectors), Type K (brown wire, yellow connectors), Cu (white wire, white connectors)
Thermocouple assemblies	K-type beaded thermocouple assembly (molded plug); J thermocouple assembly with extensions
Adapters	Cu-Cu shorting plug (white); K-type thermocouple to 4 mm banana adapter
Case	Carrying case for the set

Typical Applications

Calibrating digital multimeters, clamp meters and process meters on a 5560A, 5550A or 5540A
Thermocouple simulation and measurement (J and K types)
High-current calibration with the dedicated high-current leads
Replacing lost or worn leads to keep a calibrator’s standard kit complete

Safety Tip

Each lead type has its own rating. Use the shielded calibration leads only for calibration, and keep the stackable and high-current leads within 30 V AC / 60 V DC. Follow the calibrator manual for each function. Learn more in our guide to electrical safety standards and CAT ratings.

Need help choosing the right model or a quotation? Message our team on WhatsApp or use the quote button on this page.

Browse more calibrator accessories, multifunction calibrators, all calibrators or all Fluke products.

Fluke 55XXA/LEADS FAQ

What is the Fluke 55XXA/LEADS?

It is Fluke Calibration’s thermocouple and test lead set with case (P/N 5128204) for multi-product calibrators. It holds the leads and thermocouple parts you need for voltage, current and thermocouple calibration.

Which calibrators is the 55XXA/LEADS for?

Fluke lists it for the 5560A. The 5560A / 5550A / 5540A calibrator manual lists the 55XXA/LEADS set as standard equipment, so it is also a spare or replacement set for those models.

What is included in the set?

Stackable test leads, shielded calibration test leads, high-current test leads, 3 ft J, K and Cu thermocouple extension wires, a K-type beaded thermocouple, a J thermocouple assembly, a Cu-Cu shorting plug, a K-type to 4 mm banana adapter and a carrying case.

What are the ratings of the leads?

Per the calibrator manual: stackable and high-current leads are rated 30 V AC / 60 V DC, 30 A max; shielded calibration leads are rated 1000 V max (calibration use only, non-contact), 1500 V pk transient, 3.2 A max.

Why do the thermocouple wires have different colours?

The colours identify the wire type: black connectors for J, yellow connectors for K and white for Cu (copper). Always match the extension wire to the thermocouple type you are calibrating.
