Description

The Hioki IM7581-02 Impedance Analyzer is a cutting-edge tool designed for precise measurements in various applications. At Mohammad Mahdi Electronics, we understand the importance of accurate data in your research and development process.

Whether you’re working with LCR meters or exploring the world of Hioki instruments, our impedance analyzer is the perfect addition to your toolkit. With its LCR mode and Analyzer mode, you can perform precise measurements with ease.

Hioki IM7581-02 Key Features

The Hioki IM7581-02 Impedance Analyzer boasts an impressive range of features, including:

Measurement modes: LCR mode, Analyzer mode (Sweeps with measurement frequency and measurement level), Continuous measurement mode
Measurement parameters: Z, Y, θ, Rs (ESR), Rp, X, G, B, Cs, Cp, Ls, Lp, D (tanδ), Q
Measurable range: 100 mΩ to 5 kΩ
Display range: Z: 0.00 m to 9.99999 GΩ / Rs, Rp, X: ± (0.00 m to 9.99999 GΩ) Ls, Lp: ± (0.00000 n to 9.99999 GH) / Q: ± (0.00 to 9999.99) θ: ± (0.000° to 180.000°), Cs, Cp: ± (0.00000 p to 9.99999 GF) D: ± (0.00000 to 9.99999), Y: (0.000 n to 9.99999 GS) G, B: ± (0.000 n to 9.99999 GS), Δ%: ± (0.000 % to 999.999 %)
Basic accuracy: Z: ±0.72 % rdg. θ: ±0.41°
Measurement frequency: 100.00 kHz to 300.00 MHz (5 digits resolution)
8.4-inch color TFT with touch screen display

Who Needs the Hioki IM7581-02?

The Hioki IM7581-02 Impedance Analyzer is an essential tool for various industries, including:

Research and development teams

Manufacturing facilities

Quality control departments

Electrical engineering professionals

Anyone working with LCR meters or Hioki instruments

Hioki IM7581-02 Applications

The Hioki IM7581-02 Impedance Analyzer has a wide range of applications, including:

Measuring impedance and capacitance
Performing frequency sweeps
Measuring ESR and Rp
Measuring inductance and capacitance
Measuring Q and tanδ

Why Buy Hioki IM7581-02 from mme-ae?

Read more in our how to choose the right meter.

At Mohammad Mahdi Electronics, we offer the Hioki IM7581-02 Impedance Analyzer at competitive prices, along with excellent customer service and support. Whether you’re working with LCR meters or exploring the world of Hioki instruments, our impedance analyzer is the perfect addition to your toolkit.

Don’t settle for anything less. Buy the Hioki IM7581-02 Impedance Analyzer from mme-ae today and experience the difference for yourself.

Hioki IM7581-02 Specifications

Measurement modes	LCR mode, Analyzer mode (Sweeps with measurement frequency and measurement level), Continuous measurement mode
Measurement parameters	Z, Y, θ, Rs (ESR), Rp, X, G, B, Cs, Cp, Ls, Lp, D (tanδ), Q
Measurable range	100 mΩ to 5 kΩ
Display range	Z: 0.00 m to 9.99999 GΩ / Rs, Rp, X: ± (0.00 m to 9.99999 GΩ) Ls, Lp: ± (0.00000 n to 9.99999 GH) / Q: ± (0.00 to 9999.99) θ: ± (0.000° to 180.000°), Cs, Cp: ± (0.00000 p to 9.99999 GF) D: ± (0.00000 to 9.99999), Y: (0.000 n to 9.99999 GS) G, B: ± (0.000 n to 9.99999 GS), Δ%: ± (0.000 % to 999.999 %)
Basic accuracy	Z: ±0.72 % rdg. θ: ±0.41°
Measurement frequency	100.00 kHz to 300.00 MHz (5 digits resolution)
Measurement signal level	Power: -40.0 dBm to +7.0 dBm Voltage: 4 mV to 1001 mVrms Current: 0.09 mA to 20.02 mArms User-configured power, voltage, and current
Output impedance	50 Ω
Display	8.4-inch color TFT with touch screen
Measurement speeds *1	FAST: 0.5 ms / MED: 0.9 ms / SLOW: 2.1 ms / SLOW2: 3.7 ms *1 Analog measurement time
Functions	Contact check, Comparator, BIN measurement (classification), Panel loading/saving, Memory function, Equivalent circuit analysis, Correlation compensation
Interfaces	Handler, USB, LAN, GP-IB (optional), RS-232C (optional)
Power supply	100 to 240 V AC, 50/60 Hz, 70 VA max.
Dimensions and mass	Main unit: 215 mm (8.46 in) W × 200 mm (7.87 in) H × 268 mm (10.55 in) D, 6.5 kg (229.3 oz) Test head: 61 mm (2.40 in) W × 55 mm (2.17 in) H × 24 mm (0.94 in) D, 175 g (6.2 oz)
Included accessories	Test head ×1, Connection cable ×1, Power cord ×1, Instruction manual ×1
