Description

The Fluke 87V/E2 Industrial Electrician Combo Kit is a versatile and reliable tool for electricians and technicians. With its accurate measurements and rugged design, it’s perfect for a variety of applications, from electrical maintenance to troubleshooting.

Whether you’re working on a complex industrial project or a simple residential repair, the Fluke 87V/E2 has got you covered.

Fluke 87V/E2 Key Features

The Fluke 87V/E2 features a range of advanced measurement capabilities, including voltage, current, and resistance measurements, as well as true RMS AC measurements for accurate power analysis.

Maximum Voltage Accuracy: ±(0.05% + 1)
Maximum Resolution: 10 µV
True RMS AC Bandwidth: 20 kHz with low pass filter; 3 db @ 1 kHz
Maximum Resolution: 0.1 mV
Amps Accuracy: ±(0.2% + 2)
Maximum Resolution: 0.01 µA
Maximum Resistance: 20 MΩ
Maximum Resolution: 0.1Ω
Maximum Capacitance: 20 nF
Maximum Resolution: 0.01 nF
Maximum Frequency: 20 kHz
Maximum Resolution: 0.01 Hz
Maximum Duty Cycle: 100%
Maximum Resolution: 0.1%
Temperature Measurement Range: -200.0°C – 1090°C
Maximum Resolution: 0.1°C
Conductance Range: 1 nS
Maximum Resolution: 0.01 nS
Diode Range: 1 mV
Accuracy: ±(2% + 1)

Who Needs the Fluke 87V/E2?

The Fluke 87V/E2 is designed for electricians and technicians who need a reliable and accurate tool for a variety of applications, from electrical maintenance to troubleshooting.

Whether you’re working on a complex industrial project or a simple residential repair, the Fluke 87V/E2 has got you covered.

Fluke 87V/E2 Applications

Electrical Maintenance: Use the Fluke 87V/E2 to troubleshoot and repair electrical systems, including circuit breakers and electrical panels.
Industrial Troubleshooting: Use the Fluke 87V/E2 to diagnose and repair complex industrial electrical systems, including motors and generators.
Residential Repair: Use the Fluke 87V/E2 to troubleshoot and repair residential electrical systems, including circuit breakers and electrical panels.
Electrical Testing: Use the Fluke 87V/E2 to test electrical systems, including voltage and current measurements.
Power Quality Analysis: Use the Fluke 87V/E2 to analyze power quality, including voltage and current measurements.
Temperature Measurement: Use the Fluke 87V/E2 to measure temperature, including temperature probes and thermocouples.

Why Buy Fluke 87V/E2 from mme-ae?

At mme-ae, we offer the Fluke 87V/E2 Industrial Electrician Combo Kit at a competitive price, with a lifetime warranty and alkaline battery life.

Our team of experts is available to provide technical support and assistance, ensuring that you get the most out of your Fluke 87V/E2.

Fluke 87V/E2 Specifications

Specifications
Voltage DC	Maximum Voltage	1000 V
	Accuracy	±(0.05% + 1)
	Maximum Resolution	10 µV
Voltage AC	Maximum Voltage	1000 V
	Accuracy	±(0.7% + 2) True RMS
	AC Bandwidth	20 kHz with low pass filter; 3 db @ 1 kHz
	Maximum Resolution	0.1 mV
Current DC	Maximum Amps	10 A (20 A for 30 seconds maximum)
	Amps Accuracy	±(0.2% + 2)
	Maximum Resolution	0.01 µA
Current AC	Maximum Amps	10 A (20 A for 30 seconds maximum)
	Amps Accuracy	±(1.0% + 2) True RMS
	Maximum Resolution	0.1 µA
Resistance	Maximum Resistance	50 MΩ
	Accuracy	±(0.2% + 1)
	Maximum Resolution	0.1Ω
Capacitance	Maximum Capacitance	9,999 µF
	Accuracy	±(1% + 2)
	Maximum Resolution	0.01 nF
Frequency	Maximum Frequency	200 kHz
	Accuracy	±(0.005% + 1)
	Maximum Resolution	0.01 Hz
Duty Cycle	Maximum Duty Cycle	99.9%
	Accuracy	±(0.2% per khz +0.1%)
	Maximum Resolution	0.1%
Temperature Measurement	-200.0°C – 1090°C -328.0°F – 1994.0°F excluding probe
80 BK Temperature Probe	-40.0°C – 260°C -40.0°F – 500°F, 2.2°C or 2% whichever is greater
Conductance	Maximum Conductance	60.00 nS
	Accuracy	±(1.0% + 10)
	Maximum Resolution	0.01 nS
Diode	Range	3 V
	Resolution	1 mV
	Accuracy	±(2% + 1)
Duty Cycle Range	Accuracy	Within ±(02% per kHz +0.1%)
Environmental Specifications
Operating Temperature	-20°C to +55°C
Storage Temperature	-40°C to +60°C
Humidity (Without Condensation)	0% – 90% (0°C – 35°C) 0% – 70% (35°C – 55°C)
Operating Altitude	2000 m
Safety Specifications
Overvoltage category	EN 61010-1 to 1000 V CAT III, 600V CAT IV
Agency Approvals	UL, CSA, TÜV, VDE listed
Mechanical and General Specifications
Size	201 x 98 x 52 mm (with holster)
Weight	355 g 624 g – with holster
Display	Digital	6000 counts updates 4/sec. 19,999 counts in high-resolution mode
	Analog	32 segments, updates 40/sec.
	Frequency	19,999 counts, updates 3/sec at > 10 Hz
Warranty	Lifetime
Battery Life	Alkaline	~400 hours typical, without backlight
Shock	1 Meter drop per IEC 61010-1:2001
Vibration	Per MIL-PRF-28800 for a Class 2 instrument
