Kyoritsu 2046R AC/DC Digital Clamp Meter
Kyoritsu 2046R AC/DC Digital Clamp Meter Original price was: AED 875.Current price is: AED 723. (excl.VAT)

HIOKI DT4281 DIGITAL MULTIMETER

DIGITAL MULTIMETER DT4281 Key Features:

  • Low-pass filter cuts high harmonics
  • Terminal shutter mechanism
  • Dual display lets you check voltage and frequency simultaneously
  • Measures large currents with optional clamp probe
  • ±0.025% DC V basic accuracy, wide 20 Hz to 100 kHz AC V frequency characteristics
(1 customer review)
SKU:1144

MME Shopping Event

Hurry and get discounts on Most of MME Products up to 20%

AED 1,019 (excl.VAT)

16People watching this product now!

HIOKI DT4281 DIGITAL MULTIMETER

The Hioki DT4200 Digital Multimeter Series consist of a complete lineup of 9 models ranging from professional to industrial to pocket meters. The DT4281 is our top-of-the-line high-precision 60000-count digital multimeter with all of the functions and features required for advanced testing in complex power and electrical applications.

The DT4281’s True RMS (Root Mean Square) measurement capabilities are one of its notable characteristics. For irregular waveforms, such as those generated by electronic equipment with nonlinear loads, true RMS measurements assure accurate readings. The DT4281 is well suited for a variety of applications thanks to this capability, including industrial maintenance, troubleshooting, and research and development.

To buy Hioki DT 4281 through MME you can contact our experts. Our expert team is ready to assist you in selecting the right multimeter for your application.

Similar Products

Contact our experts to get information about the Hioki dt4281 multimeter price in MME. We offer various models of Hioki on the MME website, including:

  • Hioki DT4282:The Hioki 4282 is a precision LCR meter designed to meet the demanding needs of professionals in the field of electronics.
  • Hioki DT4261:4261, manufactured by Hioki, offers high precision and accuracy in measuring inductance, capacitance, and resistance.

more information

The Hioki DT 4281 multimeter is a handheld digital multimeter renowned for its accuracy and reliability. In this teardown, we explore its inner components and capabilities. With a wide measurement range, intuitive interface, and durable construction, the Hioki DT-4281 is an indispensable tool for professionals in electronics, electrical engineering, and maintenance.

While similar to the MME-AE, each device has unique features. Discover the power of precision with the Hioki DT 4281 multimeter.

DIGITAL MULTIMETER DT4281 Specification

  • DC Voltage: 60.000 mV to 1000.0 V, accuracy: ±0.025 % rdg
  • AC Voltage: 60.000 mV to 1000.0 V, Frequency characteristics: 20 Hz – 100 kHz, accuracy: ±0.2 % rdg
  • DC + AC Voltage: 6.0000 V to 1000.0 V, Frequency characteristics: 20 Hz – 100 kHz, accuracy: ±0.3 % rdg
  • DC Current: 600.00 μA to 600.00 mA, accuracy: ±0.05 % rdg
  • AC Current: 600.00 μA to 600.00 mA, accuracy 45 – 65 Hz: ±0.6 % rdg
  • AC Current(with clamp): 10.00 A to 1000 A, accuracy 40 – 65 Hz: ±0.6 % rdg
  • Resistance: 60.000 Ω to 600.0 MΩ, accuracy: ±0.03 % rdg
  • Capacitance: 1.000 nF to 100.0 mF, Basic accuracy: ±1.0 % rdg
  • Power supply: LR6 (AA) alkaline batteries × 4
  • Dimensions and mass: 93 mm (3.66 in) W × 197 mm (7.76 in) H× 53 mm (2.09 in) D, 650 g
5
1 review
1
0
0
0
0

1 review for HIOKI DT4281 DIGITAL MULTIMETER

Clear filters
  1. William

    Perfect tool for a set technician.

Add a review

Your email address will not be published. Required fields are marked *

You have to be logged in to be able to add photos to your review.

Brand

Hioki

datasheet

Data Sheet

Manual

Mme-Pdfs-Image

Specifications

Electrical Specifications
AC voltage range/resolution/accuracy

DC voltage range/resolution/Accuracy

AC current range/resolution/Accuracy

DC current range/resolution/Accuracy

600.00 μA to 600.00 mA/Basic A ±(0.05 % rdg)

Resistance Range/resolution/Accuracy

60.000 Ω to 600.0 MΩ/Basic A ±(0.03 % rdg)

Capacitance Range/resolution/Accuracy

1.000 nF to 100.0 mF/Basic A ±(1.0 % rdg)

Mechanical and General Specifications
Dimensions

93 mm (3.66 in) W × 197 mm (7.76 in) H× 53 mm (2.09 in) D

Weight

650 g

Power

LR6 (AA) alkaline batteries × 4
