Description

The Fluke BT510 Battery Analyzer is a specialized instrument designed for comprehensive battery testing and analysis in industrial and commercial environments. Engineers and maintenance technicians rely on this device to evaluate battery health, measure internal resistance, and verify voltage levels across various battery configurations. The instrument combines multiple measurement functions including DC voltage, AC voltage with frequency analysis, ripple detection, and resistance measurement, making it an essential tool for battery room monitoring and preventive maintenance programs.

Fluke BT510 Key Features

The Fluke BT510 delivers precise battery analysis through its advanced AC injection method, measuring battery strap resistance from 3 mΩ to 3000 mΩ with resolution as fine as 0.1 mΩ. The device features 6 VDC measurement up to 600 VAC with frequency analysis, and includes AC voltage ripple detection up to 600 mV. With the Fluke i410 accessory, current measurements reach 400 A AC. The meter stores 999 records per measurement position with time stamps, and sequence mode supports up to 100 profiles with 100 templates, each capable of storing 450 battery records for comprehensive fleet management.

Battery Resistance: 3 mΩ (strap), 30 mΩ (0.01 mΩ resolution), 300 mΩ (0.1 mΩ resolution), 3000 mΩ (1 mΩ resolution)
VDC: 6 V (0.01 mΩ resolution ranges)
VAC: 600 V (45 Hz to 500 Hz with 800 Hz filter)
Frequency: displayed with VAC and AAC up to 500 Hz
AC voltage ripple: 600 mV (20 KHz max)
ADC/AAC with Fluke i410: 400 A
Temperature range: 0°C to 60°C
Memory: 999 records per position with time stamps

Who Needs the Fluke BT510?

Battery technicians and field service engineers will find the Fluke BT510 indispensable for routine battery testing and diagnostics during preventive maintenance visits. The instrument’s ability to measure low resistance values makes it ideal for identifying cell degradation and connection issues before they lead to battery failure. Maintenance teams in data centers, telecommunications facilities, and uninterruptible power supply (UPS) rooms depend on this analyzer to verify battery string health and compliance with maintenance schedules.

Electrical engineers and facility managers responsible for critical power systems will appreciate the BT510’s comprehensive measurement capabilities and data logging features. The sequence mode functionality allows for organized battery fleet management, while the time-stamped records provide clear audit trails for compliance and warranty purposes. Buyers purchasing testing equipment for institutional or commercial applications will value the instrument’s robust construction and Fluke reliability.

Fluke BT510 Applications

The Fluke BT510 Battery Analyzer excels in UPS battery testing, where technicians must verify the health of individual cells and battery strings in uninterruptible power systems. The instrument’s low resistance measurement capability detects developing faults in battery straps and connections that could compromise power reliability during outages. Regular testing with the BT510 helps extend battery life and prevent unexpected downtime in critical facilities.

Telecommunications and data center operators rely on the BT510 for regular battery health checks in backup power systems. The device is also suitable for industrial battery applications including manufacturing equipment, emergency lighting systems, and renewable energy storage installations. The AC injection method allows testing without requiring full battery discharge, making it practical for batteries remaining in service.

Why Buy Fluke BT510 from Mohammad Mahdi Electronics?

Mohammad Mahdi Electronics provides genuine Fluke instruments with the full 3-year warranty coverage directly to customers across the UAE and Gulf region. When you purchase the Fluke BT510 from MME, you receive authentic equipment with factory calibration certificates and access to Fluke’s extensive technical support network. The mme-ae online store offers convenient ordering with secure payment options and prompt delivery to your facility.

Our team at Mohammad Mahdi Electronics understands the importance of reliable battery testing equipment for your operations. We stock the complete Fluke BT510 package including the angled measurement probes and can advise on compatible accessories like the Fluke i410 current clamp. Contact our technical specialists to discuss your specific battery testing requirements and ensure you select the right configuration for your application.

Complete your battery testing setup with genuine Fluke accessories and support from Mohammad Mahdi Electronics. Visit mme-ae today to order your Fluke BT510 Battery Analyzer and benefit from our expertise in power quality and electrical testing equipment.

Fluke BT510 Specifications

	Range	Resolution	Accuracy	BT510	BT520	BT520ANG	BT521	BT521ANG
Battery Resistance / Strap Resistance¹	3 mΩ	0.001 mΩ	1% + 8	●	●		●
			1% +68			●		●
	30 mΩ	0.01 mΩ	0.8% + 6	●	●		●
			0.8%+12			●		●
	300 mΩ	0.1 mΩ	0.8% + 6	●	●	●	●	●
	3000 mΩ	1 mΩ	0.8% + 6	●	●	●	●	●
VDC	6 V	0.001 V	0.09% + 5	●	●	●	●	●
	60 V	0.01 V	0.09% + 5	●	●	●	●	●
	600 V	0.1 V	0.09% + 5	●	●	●	●	●
	1000 V	1 V	0.09% + 5				●	●
VAC (45 Hz to 500 Hz with 800 Hz filter)	600 V	0.1 V	2% + 10	●	●	●	●	●
Frequency (displayed with VAC and AAC)²	500 Hz	0.1 Hz	0.5% + 8	●	●	●	●	●
AC voltage ripple (20 KHz Max)	600 mV	0.1 mV	3% + 20	●	●	●	●	●
	6000 mV	1 mV	3% + 10	●	●	●	●	●
ADC/AAC (with accessory Fluke i410)	400 A	1 A	3.5% + 2				●	●
Temperature	0°C to 60°C	1°C	2°C (4°F)				●	●
Meter mode	999 records for each measurement position with time stamp
Sequence mode	Up to 100 profiles and 100 profile templates (Each profile stores up to 450 batteries) with time stamp
1. The measurement is based on AC injection method. The injected source signal is < 100 mA, 1 kHz. 2. Trigger level VAC: 10 mV, AAC: 10 A
Measurement Modes	BT510			BT520			BT521
Resistance (mΩ)	●			●			●
Battery voltage	●			●			●
Voltage DC	●			●			●
Voltage AC and frequency (Hz)	●			●			●
Ripple volt	●			●			●
Temperature of negative battery post (using BTL21 straight probes)							●
DC and AC current (and frequency)							●
DMM mode	●			●			●
Sequence mode	●			●			●
Discharge measurement mode	●			●			●
Automatic measurement save	●			●			●
Wireless communication							●
Memory view	●			●			●
General Specifications – Battery Analyzer
Size (H x W x D)	22 x 10.3 x 5.8 cm (9 x 4 x 2 in)
Weight	850 g (1.9 lb)
Screen dimensions	7.7 x 5.6 cm (3 x 2.2 in)
Interface	USB mini
Warranty	3 years
General Specifications – BTL20ANG Angled Measurement Probe
Long angled probe (overall length)	242.2 cm (95.38 in)
Short angled probe (overall length)	216.8 cm (85.38 in)
Overall span (coil relaxed)	10.1 cm (4 in)
Overall maximum span (coil extended)	109.2 cm (43 in)
BTL20ANG probe tip angle	20 degrees from horizontal
Environment Specifications
Operating temperature	0°C to 40°C
Storage temperature	-20°C to 50°C
Lithium-ion battery charging temperature	0°C to 40°C
Operating humidity	Non-condensing (10°C)
	≤ 80% RH (at 10°C to 30°C)
	≤ 75% RH (at 30°C to 40°C)
Operating altitude	Sea level to 2000 meters
Storage altitude	Sea level to 12,000 meters
IP rating	IP40
Radio	FCC Class A
Vibration requirements	MIL-PRF-28800F: Class 2
Drop test requirements	1 meter
Temperature coefficients	Add 0.1 x specified accuracy for each degree C above 28°C or below 18°C
Safety compliance	600 V CAT III
EMC	IEC 61326
ROHS	China, Europe
Protection class 2	Pollution Degree II
Battery compliance	UN38.3
	UL2054
	IEC62133
	2 G per IEC68-2-26, 25 G, and 29
