Description

At Mohammad Mahdi Electronics, we offer the Hioki CM4375-90 AC/DC Clamp Meter, a high-accuracy instrument designed for electrical professionals. With its True RMS functionality, this clamp meter provides accurate measurements of AC current, making it an ideal tool for a variety of applications.

Whether you’re working on electrical panels, motors, or other equipment, the Hioki CM4375-90 is the perfect choice. Its wide measurement range and high accuracy make it a reliable instrument for any job. Plus, its compact and lightweight design makes it easy to carry and use in tight spaces.

Hioki CM4375-90 Key Features

The Hioki CM4375-90 features a range of key functions, including:

DC Current range: 1000 A, (Max. display 999.9 A)
AC Current range: 1000 A (Max. display 999.9 A, 10 Hz to 1 kHz, True RMS)
DC Voltage range: 600.0 ｍV to 1000 V
AC Voltage range: 6.000 V to 1000 V, 4 ranges
Resistance range: 600.0 Ω to 6.000 MΩ, 5 ranges
Electrostatic capacity range: 1.000 μF to 1000 μF, 4 ranges
Frequency range: 9.999 Hz to 999.9 Hz, 3 ranges
Temperature (K): -40.0°C to 400.0°C

Who Needs the Hioki CM4375-90?

The Hioki CM4375-90 is designed for electrical professionals who require a high-accuracy instrument for a variety of applications. Whether you’re working on electrical panels, motors, or other equipment, this clamp meter is the perfect choice.

At Mohammad Mahdi Electronics, we understand the importance of having the right tools for the job. That’s why we offer the Hioki CM4375-90 as part of our range of electrical instruments.

Hioki CM4375-90 Applications

The Hioki CM4375-90 is suitable for a variety of applications, including:

Electrical panel testing
Motor testing
Equipment testing
Electrical maintenance

Why Buy Hioki CM4375-90 from Mohammad Mahdi Electronics?

Browse our clamp meters. Read more in our top clamp meters for electricians. See other Hioki instruments.

At Mohammad Mahdi Electronics, we offer the Hioki CM4375-90 as part of our range of electrical instruments. We understand the importance of having the right tools for the job, and we’re committed to providing our customers with the best possible service.

Whether you’re looking for a high-accuracy instrument for electrical panel testing, motor testing, or equipment testing, the Hioki CM4375-90 is the perfect choice. Plus, with our competitive pricing and excellent customer service, you can trust that you’re getting the best possible deal.

Hioki CM4375-90 Specifications

DC Current range	1000 A, (Max. display 999.9 A) , Basic accuracy: ±1.3% rdg. ±0.3 A (at 30.1 A – 999.9 A)
AC Current range	1000 A (Max. display 999.9 A, 10 Hz to 1 kHz, True RMS), Basic accuracy 45-66 Hz: ±1.8% rdg. ±0.3 A (at 30.1 A – 900.0 A)
Crest factor	1000 A range: 1.5
DC+AC Current range	1000 A (DC, 10 Hz to 1 kHz, True RMS), Basic accuracy DC, 45-66 Hz: ±1.3% rdg. ±1.3 A (at 30.1 A – 900.0 A)
DC Power range	0.000 kVA to 1000 kVA (When using P2010: 0 kVA to 2000 kVA) (Automatically switched based on voltage range), Basic accuracy: ±2.0% rdg. ±20 dgt.
DC Voltage range	600.0 ｍV to 1000 V (When using P2010: 600.0 V to 2000 V)
AC Voltage range	6.000 V to 1000 V, 4 ranges (15 Hz to 1 kHz, True RMS), Basic accuracy 45 – 66 Hz: ±0.9% rdg. ±0.003 V (at 6 V)
DC+AC Voltage range	6.000 V to 1000 V, 4 ranges, Basic accuracy DC, 45-66 Hz: ±1.0% rdg. ±0.013 V (at 6 V)
Resistance range	600.0 Ω to 6.000 MΩ, 5 ranges, Basic accuracy: ±0.7% rdg. ±0.5 Ω (at 600 Ω)
Electrostatic capacity range	1.000 μF to 1000 μF, 4 ranges, Basic accuracy: ±1.9% rdg. ±0.005 μF (at 1 μF)
Frequency range	9.999 Hz to 999.9 Hz, 3 ranges, Basic accuracy: ±0.1% rdg. ±0.003 Hz (at 9.999 Hz)
Temperature (K)	-40.0°C to 400.0°C, add temperature probe accuracy to basic accuracy of ±0.5% rdg. ±3.0°C
Harmonic levels	[With Z3210 installed] Voltage/Current harmonic levels up to 30th, Content factor, Total harmonic distortion ratio *Harmonics can be displayed with our free app GENNECT Cross.
Other functions	Continuity check, Diode check, Automatic AC/ DC detection, DC current and DC voltage polarity detection function, MAX/MIN/AVG/ PEAK MAX/PEAK MIN value display, Low-pass filter function, Display value hold, Auto hold, Backlight, Auto power save, Buzzer sound, Zero-adjustment
Dustproof, waterproof	IP20 (Voltage measurement in a completely dry condition. When jaw closes) IP54 (While in storage)
Power supply	LR03 Alkaline battery ×2 Continuous use: approx. 40 hr (without Z3210 installed), approx. 20 hr. (with Z3210 installed and using wireless communications) Other conditions: 100 A AC measurement, backlight off, 23°C reference value
Core jaw diameter	φ34 mm (1.34 in)
Smallest dimension of jaw cross-section	9.5 mm (0.37 in) (Range value of 44 mm (1.73 in) from the tip of the jaw)
Dimensions and mass	65 mm (2.56 in) W × 242 mm (9.53 in) H × 35 mm (1.38 in) D mm, 350 g (12.3 oz)
Included accessories	Test Lead L9300, Carrying Case C0203, LR03 Alkaline battery ×2, Instruction Manual ×2, Operating Precautions ×1
