Description

At Mohammad Mahdi Electronics, we offer the Hioki CM4375-92 AC/DC Clamp Meter, a versatile and accurate tool for measuring electrical parameters. Whether you’re an electrician, engineer, or researcher, this clamp meter is designed to meet your needs.

With its True RMS measurement capability, the Hioki CM4375-92 provides accurate readings of AC and DC currents, voltages, and resistance. Its compact design and lightweight construction make it easy to carry and use in a variety of applications.

Hioki CM4375-92 Key Features

The Hioki CM4375-92 features a range of key specifications, including:

DC Current range: 1000 A, AC Current range: 1000 A
DC Voltage range: 600.0 mV to 1000 V, AC Voltage range: 6.000 V to 1000 V
Resistance range: 600.0 Ω to 6.000 MΩ, Electrostatic capacity range: 1.000 μF to 1000 μF
Frequency range: 9.999 Hz to 999.9 Hz, Temperature range: -40.0°C to 400.0°C

Who Needs the Hioki CM4375-92?

The Hioki CM4375-92 is designed for a wide range of applications, including:

Electrical maintenance and troubleshooting

Research and development

Quality control and testing

Field measurements and inspections

Hioki CM4375-92 Applications

The Hioki CM4375-92 is suitable for a variety of applications, including:

Electrical panel testing
Motor testing
Transformer testing
Power supply testing
Electrical circuit testing

Why Buy Hioki CM4375-92 from Mohammad Mahdi Electronics?

Browse our clamp meters. Read more in our top clamp meters for electricians.

At Mohammad Mahdi Electronics, we offer the Hioki CM4375-92 at a competitive price, with fast shipping and excellent customer service. We also offer a range of accessories and support services to ensure that you get the most out of your purchase.

Whether you’re looking for a reliable clamp meter for your next project or just need a replacement for your existing one, the Hioki CM4375-92 is an excellent choice. Order now and experience the difference for yourself!

Hioki CM4375-92 Specifications

DC Current range	1000 A, (Max. display 999.9 A) , Basic accuracy: ±1.3% rdg. ±0.3 A (at 30.1 A – 999.9 A)
AC Current range	1000 A (Max. display 999.9 A, 10 Hz to 1 kHz, True RMS), Basic accuracy 45-66 Hz: ±1.8% rdg. ±0.3 A (at 30.1 A – 900.0 A)
Crest factor	1000 A range: 1.5
DC+AC Current range	1000 A (DC, 10 Hz to 1 kHz, True RMS), Basic accuracy DC, 45-66 Hz: ±1.3% rdg. ±1.3 A (at 30.1 A – 900.0 A)
DC Power range	0.000 kVA to 1000 kVA (When using P2010: 0 kVA to 2000 kVA) (Automatically switched based on voltage range), Basic accuracy: ±2.0% rdg. ±20 dgt.
DC Voltage range	600.0 ｍV to 1000 V (When using P2010: 600.0 V to 2000 V)
AC Voltage range	6.000 V to 1000 V, 4 ranges (15 Hz to 1 kHz, True RMS), Basic accuracy 45 – 66 Hz: ±0.9% rdg. ±0.003 V (at 6 V)
DC+AC Voltage range	6.000 V to 1000 V, 4 ranges, Basic accuracy DC, 45-66 Hz: ±1.0% rdg. ±0.013 V (at 6 V)
Resistance range	600.0 Ω to 6.000 MΩ, 5 ranges, Basic accuracy: ±0.7% rdg. ±0.5 Ω (at 600 Ω)
Electrostatic capacity range	1.000 μF to 1000 μF, 4 ranges, Basic accuracy: ±1.9% rdg. ±0.005 μF (at 1 μF)
Frequency range	9.999 Hz to 999.9 Hz, 3 ranges, Basic accuracy: ±0.1% rdg. ±0.003 Hz (at 9.999 Hz)
Temperature (K)	-40.0°C to 400.0°C, add temperature probe accuracy to basic accuracy of ±0.5% rdg. ±3.0°C
Harmonic levels	[With Z3210 installed] Voltage/Current harmonic levels up to 30th, Content factor, Total harmonic distortion ratio *Harmonics can be displayed with our free app GENNECT Cross.
Other functions	Continuity check, Diode check, Automatic AC/ DC detection, DC current and DC voltage polarity detection function, MAX/MIN/AVG/ PEAK MAX/PEAK MIN value display, Low-pass filter function, Display value hold, Auto hold, Backlight, Auto power save, Buzzer sound, Zero-adjustment
Dustproof, waterproof	IP20 (Voltage measurement in a completely dry condition. When jaw closes) IP54 (While in storage)
Power supply	LR03 Alkaline battery ×2 Continuous use: approx. 40 hr (without Z3210 installed), approx. 20 hr. (with Z3210 installed and using wireless communications) Other conditions: 100 A AC measurement, backlight off, 23°C reference value
Core jaw diameter	φ34 mm (1.34 in)
Smallest dimension of jaw cross-section	9.5 mm (0.37 in) (Range value of 44 mm (1.73 in) from the tip of the jaw)
Dimensions and mass	65 mm (2.56 in) W × 242 mm (9.53 in) H × 35 mm (1.38 in) D mm, 350 g (12.3 oz)
Included accessories	Test Lead L9300, Carrying Case C0203, LR03 Alkaline battery ×2, Instruction Manual ×2, Operating Precautions ×1
