HIOKI DIGITAL MULTIMETER DT4222

HIOKI DIGITAL MULTIMETER DT4222 KEY FEATURES

  • Achieving a high level of safety in a compact body and lightweight design
  • ±0.5% DC V basic accuracy, wide 40 Hz to 1 kHz AC V frequency characteristics
  • Robust design capable of withstanding a drop from a height of 1 m
  • Broad -10 to 50°C (14°F to 122°F) operating temperature range



(1 customer review)
SKU:712

MME Shopping Event

Hurry and get discounts on Most of MME Products up to 20%

AED 369 (excl.VAT)

16People watching this product now!

HIOKI Digital Multimeter DT4222

The Hioki DT4200 Digital Multimeter Series consist of a complete lineup of 9 models ranging from professional to industrial to pocket meters, delivering a super fast response rate and safety features that take electrical testing to a higher level.

The DT4222 is a pocket-sized digital multimeter designed specifically for general-purpose testing, with ±0.5% DC V accuracy and wide 40 Hz to 1 kHz AC V bandwidth.

Similar Products

The Hioki 4224 is a similar product to the Hioki 4222 in terms of being a digital LCR meter manufactured by Hioki, a reputable brand of electrical measurement equipment. Both the Hioki 4224 and Hioki 4222 offer precise and reliable measurements of inductance, capacitance, and resistance. Other related products that we can mention are:

  • Hioki DT 4221
  • Hioki DT 4282
  • Hioki DT 4255

At MMElectronics, we strive to provide exceptional customer service. Our expert team is ready to assist you in selecting the right multimeter for your application.

HIOKI Digital Multimeter DT4222 Specifications

  • DC Voltage range: 600.0 mV to 600.0 V, 4 ranges, Basic accuracy: ±0.5 % rdg
  • AC Voltage range: 6.000 V to 600.0 V, 3 ranges Basic accuracy 40 – 500 Hz: ±1.0 % rdg
  • Resistance range: 600.0 Ω to 60.00 MΩ
  • Capacitance range: 1.000 μF to 10.00 mF
  • Frequency range: 99.99 Hz (5 Hz or more) to 9.999 kHz
  • Display: 4-digit LCD, max. 6000 digits, bar graph
  • Display refresh rates: 0.05 to 5 times/s, depending on the measured value
  • Power supply : LR03 alkaline batteries ×1, Continuous use: 40 hours
  • Dimensions and mass: 72 mm (2.83 in) W × 149 mm (5.87 in) H× 38 mm (1.50 in) D,190 g
  • Accessories : Test Lead DT4911 ×1, Holster ×1, Instruction manual ×1, LR03 alkaline battery ×1
5
1 review
1
0
0
0
0

1 review for HIOKI DIGITAL MULTIMETER DT4222

Clear filters
  1. Patricia

    Works well and is portable

Add a review

Your email address will not be published. Required fields are marked *

You have to be logged in to be able to add photos to your review.

Brand

Hioki

DATA sheet

Data Sheet

Specifications

Electrical Specifications
AC voltage range/resolution/accuracy

DC voltage range/resolution/Accuracy

Resistance Range/resolution/Accuracy

600.0 Ω to 60.00 MΩ

Capacitance Range/resolution/Accuracy

1.000 μF to 10.00 mF

Frequency range/resolution/Accuracy

99.99 Hz (5 Hz or more) to 9.999 kHz/Basic A ±(0.1%rdg±1dgt)

Mechanical and General Specifications
Dimensions

72 mm (2.83 in) W × 149 mm (5.87 in) H× 38 mm (1.50 in)

Weight

190 g

Power

Continuous use: 40 hours, LR03 alkaline batteries ×1

More
Continuity test

Data Hold

Diode test

Display-count

6000 counts

Relative mode

Display Hold

AUTO/MANUAL

Backlight
