Hioki DT4261 Digital Multimeter
Short Description:
HIOKI DT4261 DIGITAL MULTIMETER Key Features:
- Display : Main and sub displays: 4-digits LCD, max. 6000 digits (excluding frequency measurement), bar-graph
- Display refresh rates : 5 times/s (Capacitance measurement: 0.05 to 5 times/s, depending on measured value, Frequency: 1 to 2 times/s
- Power supply : LR6 (AA) alkaline batteries × 3, Continuous operating time: 130 hr. (without Z3210 installed), 70 hr.
Product purchase
AED 859 (excl.VAT)
17
People watching this product now!
Terms of sending goods ›
Description
Hioki mid-range DMM, the DT4261, is an exceptional support tool with multifaceted functionality designed to help analyze a variety of issues and boost work efficiency.
Other functions: Mis-insertion prevention shutters, fuse check function, user setting retention function, filter function, zero-adjustment, display value hold, auto hold, MAX/MIN value display, PEAK value display, auto-power save, USB communication (when optional Communication Package DT4900-01 is installed), wireless communication (when optional Wireless Adapter Z3210 is installed)
Looking to buy Hioki DT 4261 multimeter in Dubai? You can find it on the MME-AE website. Obtain this multifunctional instrument.MME-AE provides an easy platform for purchasing the Hioki DT4261 multimeter whether you are in Dubai or elsewhere. Don’t pass up this strong instrument for electrical and thermal measurement. You can also contact our experts at MMElectronics to know the price of other Hioki multimeters such as the Hioki DT4261 Digital Multimeter.
Related Products
- Hioki DT4281:The Hioki 4281 is a precision LCR meter designed for professionals and researchers who require accurate and reliable measurements of inductance, capacitance, and resistance.
- Hioki DT4282: The Hioki 4282 is a precision LCR meter designed to meet the demanding needs of professionals in the field of electronics
Hioki DT 4261 Specifications:
- DC /AC Voltage range: 600.0 mV to 1000 V
- Resistance range: 600.0 Ω to 60.00 MΩ
- DC / AC Current range: 600.0 mA to 10.00 A
- Capacitance range: 1.000 μF to 10.00 mF
- Voltage frequency range: 99.99 Hz to 99.99 kHz
- Display: Main and sub displays: 4-digit LCD, max. 6000 digits
- Power supply : LR6 (AA) alkaline batteries × 3
- Dimensions and mass: 87 mm (3.43 in.) W × 185 mm (7.28 in.) H × 47 mm (1.85 in.) D, 480 g (16.9 oz.)
- Accessories : Test Lead L9300 × 1, Instruction Manual × 1, LR6 (AA) alkaline battery × 3, Operating Precautions ×1
Additional information
| AC voltage range/resolution/accuracy | |
|---|---|
| DC voltage range/resolution/Accuracy | |
| AC current range/resolution/Accuracy | |
| DC current range/resolution/Accuracy |
600.0mA to 10.00A/Basic A ±(0.5%rdg.±3dgt) |
| Resistance Range/resolution/Accuracy |
600.0Ω to 60.00MΩ/Basic A ±(0.7%rdg.±3dgt) |
| Capacitance Range/resolution/Accuracy |
1.000μF to 10.00mF/Basic A ±(1.9%rdg.±5dgt) |
| Frequency range/resolution/Accuracy |
99.99Hz to 99.99kHz/Basic A ±(0.1%rdg.±1dgt) |
| Continuity test |
√ |
| Data Hold |
√ |
| Diode test |
√ |
| Duty cycle |
√ |
| MIN - MAX |
√ |
| Peak Hold |
√ |
| Display-count |
6000 counts |
| Auto Hold |
√ |
| Display Hold |
√ |
| Dimensions |
87×185×47 |
| Weight |
480 g |
| Power |
LR6 (AA) alkaline batteries × 3 |
| Accessories |
Instruction Manual × 1 ,Operating Precautions ×1 ,Test Lead L9300 × 1 |
| Operating temperature |
-25℃ to 65℃ |
| Storage temperature |
-30℃ to 70℃ |
Data Sheet
Data Sheet
–
Specifications
Specifications
| Category | Specification | Detail |
|---|---|---|
| Voltage Range | DC Voltage Range | 600.0 mV to 1000 V, 5 ranges, Basic accuracy: ±0.15% rdg. ±2 dgt. |
| AC Voltage Range | 6.000 V to 1000 V, 4 ranges, Basic accuracy 40 Hz – 500 Hz: ±0.9% rdg. ±3 dgt. (True RMS, crest factor 3 or less) | |
| DC + AC Voltage Range | 6.000 V to 1000 V, 4 ranges, Basic accuracy DC, 40 Hz – 500 Hz: ±1.0% rdg. ±13 dgt. (True RMS, crest factor 3 or less) | |
| LoZ V | Low Impedance Voltage | 600.0 V, 1 range, Basic accuracy DC, 40 Hz – 500 Hz: ±1.0% rdg. ±13 dgt. (True RMS, crest factor 3 or less) |
| Resistance Range | 600.0 Ω to 60.00 MΩ, 6 ranges, Basic accuracy: ±0.7% rdg. ±3 dgt. | |
| Current Range | DC Current Range | 600.0 mA to 10.00 A, 3 ranges, Basic accuracy: ±0.5% rdg. ±3 dgt. |
| AC Current Range | 600.0 mA to 10.00 A, 3 ranges, Basic accuracy 40 Hz – 500 Hz: ±1.4% rdg. ±3 dgt. (True RMS, crest factor 3 or less) | |
| Capacitance Range | 1.000 μF to 10.00 mF, 5 ranges, Basic accuracy: ±1.9% rdg. ±5 dgt. | |
| Frequency Range | Voltage Frequency Range | 99.99 Hz to 99.99 kHz, 4 ranges, Basic accuracy: ±0.1% rdg. ±1 dgt. |
| Other Functions | Mis-insertion prevention shutters, fuse check, user setting retention, filter function, zero-adjustment, display value hold, auto hold, MAX/MIN/PEAK value display, auto-power save, USB and wireless communication options | |
| Power Supply | LR6 (AA) alkaline batteries × 3, Continuous operating time: 130 hr. (without wireless communication), 70 hr. (with wireless communication) | |
| Dimensions and Mass | 87 mm W × 185 mm H × 47 mm D, 480 g (with test leads holder and batteries) | |
| Included Accessories | Test Lead L9300 × 1, Instruction Manual × 1, LR6 (AA) batteries × 3, Operating Precautions ×1 | |
