Description

At Mohammad Mahdi Electronics, we offer the Hioki NON-CONTACT CAN SENSOR SP7001, a cutting-edge non-contact CAN sensor designed for detecting CAN signals without physical contact. This innovative sensor utilizes capacitive-coupled signal detection method, ensuring reliable signal detection and transmission.

The SP7001 is compatible with current accessories and is ideal for use in various applications, including automotive and industrial systems. For more information on the top clamp meters for electricians, visit our blog.

Hioki SP7001 Key Features

The Hioki SP7001 offers several key features, including:

1 CH (SP7150), 2 CH (SP7100) for simultaneous signal detection.
125 kbit/s to 3 Mbit/s for high-speed signal detection.
130 ns (typical) total delay time for fast data acquisition.
60 Ω (typical) CAN terminal resistance for secure signal transmission.
D-sub 9-pin female signal output connector for easy integration.
USB bus power for convenient power supply.

Who Needs the Hioki SP7001?

The Hioki SP7001 is designed for use in various applications, including:

Automotive systems, such as Hioki instruments and automotive electronics.

Industrial systems, such as manufacturing and process control.

Research and development, such as testing and validation.

Hioki SP7001 Applications

The Hioki SP7001 is suitable for use in various applications, including:

Automotive systems

Industrial systems

Research and development

Why Buy Hioki SP7001 from mme-ae?

At mme-ae, we offer the Hioki SP7001 at competitive prices, along with excellent customer service and support. For more information, visit our website or contact us today.

For more information on the top clamp meters for electricians, visit our blog.

Hioki SP7001 Specifications

Detection method	Capacitive-coupled signal detection No bare-wire connections
Detectable cables	AVS/AVSS-compliant cables, External diameter: 1.2 mm (0.05 in.) to 2.0 mm (0.08 in.)
Number of channels	1 CH (SP7150), 2 CH (SP7100)
Compatible communications speeds	CAN, CAN FD 125 kbit/s to 3 Mbit/s
Total delay time	130 ns (typical)
CAN terminal resistance	60 Ω (typical), built-in
Signal output connector	D-sub 9-pin female
Operating temperature, humidity	Temperature: -40 °C to 85 °C (-40 °F to 185 °F) Humidity: -40 °C to 60 °C (-40 °F to 140 °F), 80% RH or less (with no condensation), 60 °C to 85 °C (140 °F to 185 °F), 60% RH or less (with no condensation)
Power supply	(1) SP7150 – USB bus power (5 V DC), Maximum rated power: 1 VA – Z1013 AC Adapter: Rated supply voltage: 100 V to 240 V AC, Maximum rated power: 6 VA (including AC adapter), 1 VA (product only) (2) SP7100 – Z1008 AC Adapter: Rated supply voltage: 100 V to 240 V AC, Maximum rated power: 8 VA (including AC adapter), 3 VA (product only) – External power supply: Rated supply voltage: 10 V to 30 V DC, Maximum rated power: 3 VA
Dimensions and mass (*1)	SP7001: 44 W × 85 H × 20 D mm (1.73 in. W × 3.35 in. H × 0.79 in. D), 180 g (6.35 oz.), Cable length: 2.5 m (8.20 ft.) SP7100: 55 W × 120 H × 25 D mm (2.17 in. W × 4.72 in. H × 0.98 in. D),130 g (4.59 oz.), Cable length: 0.3 m (0.98 ft.) SP7150: 47 W × 100 H × 20 D mm (1.85 in. W × 3.94 in. H × 0.79 in. D),100 g (3.52 oz.), Cable length: 0.3 m (0.98 ft.) SP9250:10.5 W × 24.5 H × 101 D mm (0.41 in. W × 0.96 in. H × 3.98 in. D),45 g (1.59 oz.), Cable length: 0.8 m (2.62 ft.) SP9200: φ11.6 × 33.7 H mm (φ0.46 in. × 1.33 in.), 26 g (0.92 oz.), Cable length: 0.5 m (1.64 ft.)
Included accessories (SP7001)	Quick Start Manual ×1, Operating Precautions ×1
Included accessories (SP7100)	Quick Start Manual ×1, Operating Precautions ×1, Spiral tube ×1, Power cable L9500 ×1, Alligator clip ×1, Ground connection cable ×1
Included accessories (SP7150)	Quick Start Manual ×1, Operating Precautions ×1, Spiral tube (for fixing power cable) ×1, USB Cable L9510 ×1, Ground connection cable ×1, Alligator clip ×1
