Kyoritsu KEW 4106 Earth Resistance and Resistivity Tester

Overview

The Kyoritsu KEW 4106 is a professional digital earth resistance and soil-resistivity tester for demanding earthing measurements. Supporting 2-, 3- and 4-pole methods, it measures both earth resistance and, using the 4-pole (Wenner) method, soil resistivity — the key data engineers need to design earthing systems for substations, towers and large installations. It covers everything from in-house wiring and appliances to power distribution lines.

A standout feature is its advanced noise handling: an FFT-based filtering method and four selectable test-current frequencies (94 / 105 / 111 / 128 Hz, automatic or manual) let it make accurate measurements even in electrically noisy environments near live power lines. A high test current (up to 80 mA) and a low output voltage (10 Vrms or lower) support reliable readings, and the large graphic backlit display can show auxiliary-spike resistance, test-current frequency, interference voltage/frequency and residual resistance Rk. Up to 800 results are stored in memory and transferred to a PC with the KEW Report software via USB. The instrument has a robust IP54-rated housing.

Key Features

• 2/3/4-pole digital earth resistance and soil-resistivity tester.
• 4-pole (Wenner) soil-resistivity measurement for earthing-system design.
• FFT-based filtering with four selectable frequencies (94/105/111/128 Hz).
• High test current up to 80 mA; output voltage 10 Vrms or lower.
• Large graphic backlit display shows spike resistance, noise and residual resistance Rk.
• Stores up to 800 results; KEW Report PC software via USB.
• Robust IP54-rated housing.

Applications

• Earth-resistance testing of installations from in-house wiring to distribution lines.
• Soil-resistivity surveys (4-pole Wenner) for earthing-system design.
• Accurate measurement in electrically noisy environments.
• Substation, tower and large-installation earthing verification.

What’s in the Box

• KEW 4106 earth resistance and resistivity tester.
• Auxiliary earth spikes and cable reels/leads.
• KEW Report software and USB adapter.
• Batteries, carrying case and instruction manual.

Kit contents may vary by order; contact MME to confirm your configuration.

Why buy from MME in UAE

MOHAMMAD MAHDI Electronics Trading LLC (MME) is a trusted supplier of Kyoritsu test and measurement equipment across the UAE and the wider Gulf region. We offer genuine Kyoritsu products, competitive pricing, expert application support and reliable after-sales service to keep your earthing tests running smoothly.

View the Kyoritsu KEW 4106 datasheet
