Megger DET24C Digital Earth Clamp Tester
(No Reviews)
Key Features:
- The elliptical clamp shape improves access to earth cables and straps up to 50 mm
- Low maintenance flat jaw interface
- Measures ground resistance from 0.05 Ω to 1500 Ω
- Measures true RMS ground leakage current from 0.5 mA rms to 35 A rms
- CAT IV 600 V safety rating
- Backlit LCD display
Terms of sending goods ›
AED 9,680 (excl.VAT)
Order Via phone number
In stockDelivers in 2-3 business days.
Description
Introduction of Megger DET24C
The Megger DET24C digital earth clamp represents the latest generation of clamp-on resistance testers. These instruments introduce a test current into earth systems, measuring ground resistance in multi-ground installations without requiring ground disconnection. They provide industry-leading access, advanced features, user-friendly operation, and CAT IV 600 V safety protection.
The DET24C also features a true RMS AC measurement capability of up to 35 Amps. Its ability to measure current flowing through an earth cable adds an important safety dimension, particularly when the earth cable needs to be disconnected.
This clamp-on stakeless earth tester can also:
- Balance elements of the ground to mitigate noise
- Balance ground circuits
- Measure continuity of ground circuits in headends and hubs
Datasheet
Datasheet
Specifications
Specifications
| Ground Resistance | ||
| Range | Resolution | Intrinsic Certainty |
| 0.05 Ω to 0.99 Ω | 0.01 Ω | ±1.5% ±0.05 Ω |
| 1.00 Ω to 9.99 Ω | 0.01 Ω | ±1.5% ±0.1 Ω |
| 10.0 Ω to 99.9 Ω | 0.1 Ω | ±2% ±0.5 Ω |
| 100.0 Ω to 199.9 Ω | 0.1 Ω | ±5% ±1 Ω |
| 200 Ω to 400 Ω | 1 Ω | ±10% ±10 Ω |
| 400 Ω to 600 Ω | 1 Ω | ±10% ±10 Ω |
| 600 Ω to 1200 Ω | 10 Ω | ±20% |
| 1200 Ω to 1500 Ω | 10 Ω | ±35% |
| Frequency of measurement | 1390 Hz | |
| Note: The specification stated above is only maintained if the Jaws of the DET14C and DET24C are kept clean at all times. | ||
| Alarm Settings | ||
| Type | Range | Resolution |
| Threshold 1 | 1 Ω to 1500 Ω | 1 Ω |
| Threshold 2 | 1 Ω to 1500 Ω | 1 Ω |
| Current Measurement (RMS) | ||
| Range | Resolution | Intrinsic Certainty |
| 0.5 mA to 0.99 mA | 0.01 mA | ±2% ±0.05 mA |
| 1.00 mA to 9.99 mA | 0.01 mA | ±2% ±0.05 mA |
| 10.0 mA to 99.9 mA | 0.1 mA | ±2% ±0.1 mA |
| 100 mA to 999 mA | 1 mA | ±2% ±1 mA |
| 1.00 A to 9.99 A | 0.01 A | ±2% ±0.01 A |
| 10.0 A to 35.0 A | 0.1 A | ±2% ±0.1 A |
| True RMS readings up to a crest factor of 5.0 (peak current 40 A). | ||
| Accuracy guaranteed for 50 Hz and 60 Hz. | ||
| Measurement over the range 16 Hz to 400 Hz. | ||
| Maximum current: 100 A rms continuous and 200 A rms for 60 s max at 50 Hz and 60 Hz | ||
| Physical Characteristics | ||
| Parameter | Details | |
| Maximum jaw opening | 39 mm | |
| Maximum jaw inner dimensions | 39 mm x 55 mm | |
| Display | 4 + 6 digit with backlight | |
| Battery type | 4 x 1.5 V IEC LR6/AA alkaline | |
| Battery life | 24 hours continuous testing – see Note 1 | |
| Note 1: Whilst measuring a 25 Ω resistance without backlight | ||
| Auto power down | 300 s (reset by jaw action or button press) | |
| Data logging | DET14C: 256 records, DET24C: 2 k records | |
| Data download | Bluetooth® interface (DET24C only) | |
| Range selection | Automatic within each mode | |
| Sampling time | <1 s | |
| Hold function | Yes with visual indicator | |
| Alarm function | Yes with visual indicator | |
| Alarm/warning buzzer | Yes | |
| Operating temperature range and humidity | -20 °C to +50 °C, <85% RH | |
| Storage temperature range and humidity | -40 °C to +60 °C, <75% RH | |
| IP rating | IP30 with jaws closed | |
| Safety | EN 61010-2-032, CAT IV 600 V, Pollution degree 2 | |
| EMC | Class B Compliant, IEC 61326, BSEN 61326 | |
| Dimensions | 248 mm (l) x 114 mm (b) x 49 mm (h) | |
| Weight | 985 g | |
