Megger AVO840 True RMS Digital Multimeter
Click to enlarge

    Megger AVO840 TRMS Digital Multimeter – 1000V | Low-Z, Bluetooth & IP44 Rugged Design

    Compare
    (No Reviews)

    The Megger AVO840 TRMS Digital Multimeter is engineered for electricians and engineers who demand precision, ruggedness, and smart connectivity. With True RMS accuracy, Low-Z mode, IP44 protection, and Bluetooth data logging, it ensures dependable results for industrial, commercial, and HVAC applications.

    Terms of sending goods ›
    • In-stock items are delivered within 2 business days.
    • We are not Supporting COD Payments Terms Outside UAE
    • For out-of-stock items, delivery may take 2 to 4 business weeks.
    SKU: 125090 Category:
    Brand:Megger

    AED 1,089 (excl.VAT)

    Order in WhatsApp
    Order Via phone number
    In stockDelivers in 2-3 business days.
    Description

    Megger AVO840 TRMS 1000 V AC/DC Digital Multimeter overview

    The Megger AVO840 TRMS Digital Multimeter is a professional-grade diagnostic tool designed for industrial electricians, HVAC specialists, service engineers, and renewable energy technicians.

    Unlike standard multimeters, the AVO840 stands out with its Low-Z mode that eliminates ghost voltages — a common problem in live and complex electrical environments. This ensures accurate, stable, and safe readings even in distribution panels, motor control centers, and modern electronic systems.

    The instrument provides a comprehensive measurement range, covering AC/DC voltage up to 1000 V, current up to 10 A, resistance, continuity, capacitance (up to 6000 µF), diode checks, frequency, duty cycle, and temperature measurement with a K-type thermocouple.

    Connectivity is a game-changer with built-in Bluetooth support. Pair the meter with the Megger AVO Link app (iOS & Android) to log data wirelessly, generate trend graphs, and share reports instantly with colleagues or clients.

    Built for harsh environments, the AVO840 features IP44 ingress protection, is drop-tested to 2 meters, and housed in a rugged double-moulded case, ensuring reliability in demanding fieldwork. Its 6000-count backlit LCD with analogue bar graph provides fast, intuitive visualization of fluctuating signals, even in poor lighting.

    Whether you’re working in industrial power systems, HVAC diagnostics, renewable energy setups, or electrical panel testing, the Megger AVO840 combines precision, durability, and connectivity to deliver professional results every time.

    Megger AVO840 Key Features

    • True RMS measurements: Accurate readings on both linear and non-linear loads.
    • Wide measurement range: AC/DC voltage up to 1000 V, current up to 10 A, resistance, continuity, diode, capacitance, frequency, and temperature with K-type thermocouple.
    • Low-Z mode: Eliminates ghost voltages for reliable results in live circuits.
    • Rugged and safe: IP44 ingress protection, drop-tested to 2 meters, CAT IV 600 V / CAT III 1000 V safety ratings.
    • Intuitive display: Backlit 6000-count LCD with analogue bar graph for fast, clear readings.
    • Bluetooth connectivity: Wireless data logging and reporting via the Megger AVO Link app.

    What’s in the Box Megger AVO840

    Contents of the Megger AVO840 Digital Multimeter box

    • Megger AVO840 multimeter
    • 1 m 4 mm non-fused, right angle connector test leads* (x2)
    • 4 mm exposed metal Probes* (x2)
    • Exposed tip probes for CAT II probing (x2)
    • Red and black crocodile clips*
    • K-type multimeter adapter
    • K-type thermocouple lead
    • Soft case
    • 4 mm cap plugs (x2)
    • Batteries AAA Alkaline (x4)
    Datasheet

    Datasheet

    Mme-pdfs-image

    Specifications

    Specifications

    Megger AVO840 Specifications

    Function Range Resolution Accuracy ±(% of Reading + Digits)
    AC Voltage 6 V 1 mV ±(0.8% + 8)
    60 V 10 mV ±(0.8% + 8)
    600 V 0.1 V ±(0.8% + 8)
    1000 V 1 V ±(1.0% + 3)
    DC Voltage 600 mV 0.1 mV ±(0.5% + 8)
    6 V 1 mV ±(0.5% + 5)
    60 V 10 mV ±(0.5% + 5)
    600 V 0.1 V ±(0.8% + 3)
    1000 V 1 V ±(0.8% + 3)
    Low-Z AC Voltage 6 V 1 mV ±(3.0% + 40)
    60 V 10 mV ±(3.0% + 40)
    600 V 0.1 V ±(3.0% + 40)
    Low-Z DC Voltage 600 mV 0.1 mV ±(3.0% + 40)
    6 V 1 mV ±(3.0% + 40)
    60 V 10 mV ±(3.0% + 40)
    600 V 0.1 V ±(3.0% + 40)
    Frequency 9.999 Hz – 9.999 kHz 0.001 Hz – 1 Hz ±(1.0% + 5)
    Duty Cycle 20.0% – 80.0% 0.1% ±(1.2% + 2)
    AC Current 600 μA – 10 A 0.1 μA – 10 mA ±(1.5% + 3) – ±(2.0% + 5)
    DC Current 600 μA – 10 A 0.1 μA – 10 mA ±(1.0% + 3) – ±(1.5% + 3)
    Resistance 600 Ω – 60 MΩ 0.1 Ω – 10 kΩ ±(1.0% + 5) – ±(2.0% + 10)
    Capacitance 60 nF – 6000 μF 10 pF – 1 μF ±(3.0% + 5) – ±(5.0% + 35)
    Temperature -20°C – 760°C / -4°F – 1400°F 0.1°C / 0.1°F ±(1.0% + 5°C / 9°F)

    Environmental & General Specifications

    Specification Details
    Insulation Class 2, double insulation
    Enclosure Double moulded, IP44
    Diode Test 1 mA typical, open circuit voltage 3 V typical
    Continuity Test Audible signal if resistance <50 Ω
    Battery Four AAA 1.5 V alkaline (pre-installed)
    Display 6000 count LCD
    Over Range Indication “OL” displayed
    Polarity Automatic; minus (-) sign for negative
    Measurement Rate 3 readings per second
    Auto Power Off After approx. 15 minutes of inactivity
    Input Impedance >10 MΩ DC, >9 MΩ AC
    Low-Z Impedance Approx. 3 kΩ
    Temperature Sensor K-type thermocouple required
    AC Response True RMS
    ACV Bandwidth 50 Hz – 1 kHz
    Transducer Current Max 3000 A
    Size (H x W x D) 170 x 74 x 45 mm (6.7 x 2.9 x 1.8 in)
    Weight 370 g (417 g with battery)
    F1 Fuse (A Inputs) 10 A, 1000 V, 30 kA
    F2 Fuse (mA Input) 800 mA, 1000 V, 30 kA
