PCE-TG 150 Ultrasonic Thickness Gauge

The PCE-TG 150 Material Thickness Meter is a top-of-the-line solution for all your material measurement needs. Its versatile capabilities, limit value function, data memory, and optional ISO calibration certificate make it a reliable and user-friendly device. If you want to enhance your projects’ efficiency and accuracy, head over to mme.ae and check out the PCE-TG 150 now!

SKU:63441

MME Shopping Event

Hurry and get discounts on Most of MME Products up to 20%

AED 2,100 (excl.VAT)

13People watching this product now!

PCE-TG 150 Ultrasonic Thickness Gauge

Are you in need of a versatile and reliable material thickness meter that can handle a wide range of measurement tasks? Look no further than the PCE-TG 150! This innovative device, available on the mme.ae website, offers cutting-edge measurement capabilities that are sure to meet your needs.

Versatile Measurement Capabilities:

The PCE TG 150 comes equipped with an adjustable speed of sound feature, allowing it to measure materials up to an impressive 300 mm thick accurately. Whether you’re dealing with steel, aluminum, zinc, silver, gold, or other materials, this meter has covered you. The stored speed of sound data ensures its universality and efficiency across various applications.

Limit Value Function for Enhanced Control:

With the PCE TG150, users can set maximum and minimum values for measurements, receiving visual and acoustic signals if measurements deviate from the predetermined limits. This function allows for enhanced quality control, making sure your projects stay within the desired parameters.

Data Memory and Analysis:

Keeping track of measurements is a breeze with the data memory feature of the PCE-TG 150. It allows you to record and analyze measured values with graphical representations for easy visualization and interpretation. The device also displays average, largest, and smallest measured values, simplifying data analysis and decision-making.

Optionally Equipped with ISO Calibration Certificate:

The PCE-TG 150 offers an optional ISO calibration certificate for those seeking the utmost precision and accuracy. This certificate provides additional assurance, giving you the confidence you need in critical applications. to buy PCE TG 150 in Dubai visit the mme-ae website.

PCE-TG 150 Specifications:

  • Measuring range: 1.00-300.0 mm / 0.04-11.81″
  • Resolution: 0.01 mm at ≤99.99 mm, 0.1 mm at ≥100.0 mm
  • Accuracy: ±0.5 % of measured value + 0.05 mm
  • Storage space: 1500 measured values
  • Probe frequency: 5 MHz / 2.5 MHz
  • Standard sensor: PCE-TG 5M10d
  • Adjustable speed of sound: 1000-9999 m/s
  • Smallest pipe diameter: Ø20 x 3 mm (steel)
  • Material library: 15 memory locations
  • Calibration reference: 4 mm
  • Display: 2.4 inch TFT LCD color display with brightness adjustment
  • Power supply: 3 x 1.5 V AA batteries
  • Automatic switch-off: switched off, 2, 5, 10, 30 minutes
  • Ambient conditions: 0-40 °C / 32-104 °F, <90 % RH, non-condensing
  • Dimensions:163 x 82 x 38 mm / 6.4 x 3.2 x 1.5″
  • Weight:320 g / 11.2 oz

Pce Tg 150 Material Thickness Meter

0 reviews
0
0
0
0
0

There are no reviews yet.

Be the first to review “PCE-TG 150 Ultrasonic Thickness Gauge”

Your email address will not be published. Required fields are marked *

You have to be logged in to be able to add photos to your review.

Brand

Pce

PCE Instruments is a reliable brand that provides a wide range of high-quality measuring tools for industries such as laboratory testing, industrial manufacturing, and environmental monitoring. With a team of highly skilled engineers and scientists, PCE Instruments develops innovative products in-house to ensure quality and precision. The brand has a world-class reputation for reliability, durability, and accuracy.

pce logo brand3

Manual

Manual

Manual

Specifications

ultrasonic thickness gauge
measuring range/resolution/accuracy

0.04-11.81", 1.00-300.0 mm

measuring units

inch, mm

probe diameter

Ø20 x 3 mm

probe types

Steel

Mechanical and General Specifications
Dimensions

163 x 82 x 38 mm, 6.4 x 3.2 x 1.5"

Weight

11.2 oz, 320 g

Power

3 x 1.5 V AA batteries

Other features of the device

Ambient conditions: 0-40 °C / 32-104 °F, <90 % RH, non-condensing, Calibration reference: 4 mm, Material library: 15 memory locations

More
Automatic shutdown

auto power off

data recording

1500 measured values
